Xcmg Truck Crane (QY12K)

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Sets)	Unit Price
1.0	US $ 8000/ Piece

Price:US $8000.0 / Piece

Trade Terms: FOB, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW

Payment Terms: L/C, T/T, D/P, Paypal, Money Gram, Western Union

Price Valid Time:From Apr 17, 2015 To Jul 31, 2016

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:QY12K

Application:Construction Usage

Certification:ISO9001: 2000, CE

Condition:New

Export Markets:South America, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia

Additional Info.

Trademark:XCMG

Packing:Nude

Standard:Euro III

Origin:Jiangsu, China

HS Code:8426990000

Production Capacity:30 Sets Per Month

Product Description

XCMG QY12K Truck Crane
1. Two axles
2. CAT EURO III electric injection engine, full coverage board
3.3-section hexagonal conformation mast booms and no jibs, independent winch, weighing instrument and cooling and heating air conditioner
4. Total dimension(mm): 10200*2500*3200
5. Max. Grade-ability: 26%
6. Total mass in travel state(Kg): 16000
7. Max. Operation weight(Kg): 12000

Wide cab
Five-segment U section boom
Single cylinder luffing and double-winch
Manual mechanical control
Spacious and luxury streamline cab
U boom system
Constantly optimize the boom section, completely releasing the carrying capacity of the plates, which makes the lifting more reliable and safer.
Compact boom head
Extend the jib length, which can extend the working radius to the most.
Hydraulic pipeline
The pipeline adopts high-precision cold drawing steel pipe, matching with the cutting ferrule, which is good looking and easy to maintain.
Operating cab
It has large space and wide views. The control levers and instrument buttons are at hand.
Torque limiter
The colorful LCD display of the torque limiter can shows all the important operating information.
Engine
Reasonable matching, energy efficiency and environmental protection, and strong power meet the economical running of the required power.

Dimension	Unit	QY12B.5
Overall length	mm	10200
Overall width	mm	2500
Overall height	mm	3200
Weight
Total weight in travel	kg	16000
Front axle load	kg	6000
Rear axle load	kg	10000
Power
Engine model		6C215\WD415.21\SC8DK230Q3
Engine rated power	kW/(r/min)	158/2200\155/2200\170/2200 790/1400\820/1400\830/1400
Engine rated torque	N.m/(r/min)	158/2200\155/2200\170/2200 790/1400\820/1400\830/1400
Travel
Max. travel speed	km/h	68\75
Min. turning diameter	mm	18000
Min. ground clearance	mm	260
Approach angle	°	21
Departure angle	°	10
Max. grade ability	%	?26\?28
Fuel consumption for 100km	L	30\ 40
Main performance
Max. rated total lifting capacity	t	12
Min. rated working radius	m	3
Turning radius at turntable tail	m	2.6
Max. lifting torque	kN.m	428
Base boom	m	9.3
Fully extended boom	m	23
Fully extended boom+jib	m	29.4
Longitudinal outrigger span	m	4.1
Lateral outrigger span	m	4.9
Working speed
Boom luffing time	s	50
Boom full extension time	s	75
Max. swing speed	r/min	2.6
Main winch full load/no load (single rope)	m/min	110
