XCMG 102mm Horizontal Directional Drill Drill Diameter (XZ680)

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 10000/ Piece

Price:US $10000.0 / Piece

Trade Terms: FOB, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW

Payment Terms: L/C, T/T, D/P, Paypal, Money Gram, Western Union

Price Valid Time:From Jul 29, 2015 To Dec 31, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:XZ680

Type:Geothermal Drilling Rig

Drill Direction:Vertical

Depth of Drilling:>300 M

Drilling Speed:>100 M/H

Automation:Semi-automatic

Layout:Horizontal

Control:Artificial

Precision:Normal Precision

Application:Machinery & Hardware, Art & Craft, Construction, Mineral Industry, Stone Industry

Certification:API, CCC, UL, SONCAP, GOST, ISO, CE

Engine:Cumins

Rated Power:250kw

Overall Weight:25000kg

Export Markets:Global

Dimension(Lxwxh):11000* 2800* 3300mm

Additional Info.

Trademark:XCMG

Packing:Nude Package

Standard:CE

Origin:Jiangsu, China

HS Code:84306919

Production Capacity:30 Sets/Month

Product Description

Product Description
XCMG Horizontal Directional Drill XZ680
1. CUMINS engine
2. Rated Power: 250 kw
3. Pull Force: 680KN
4. Output Torque: 27000N. M
5. Max. Power head speed: 0-100r/min
6. Operating Weight: 25000kg
7. Dimension(L*W*H): 1000* 2800* 3300mm

Technical Features of XZ680:

@XZ680 adopts many advanced control technologies such as PLC control, electro-hydraulic proportional control, load sensing control, and etc.

@The drilling shaft can be mounted and dismounted automatically, so as to improve the work efficiency and reduce the labour intensity and manual misoperation and thus reduce the work staff and reduce the production cost.

@Automatic anchoring: The hydraulic pressure drives the anchor, which features large anchoring force, simple and convenient operation.

@Dual speed power head: Drilling and dragging at low speed to ensure that it works smoothly; Sliding at quick speed to reduce the auxiliary time and make higher work efficiency during the disassembly of drilling rig with empty load.

@The engine has the feature of turbocharged torque increase, which can increase the power instantaneously when encountering tough terrains to ensure the drilling power.

@The power head features high speed, good boring effect and high efficiency.

@Multiple operation with single handle control, convenient for accurate control, simple and comfortable operation.

@With tethered control, it is safe and efficient for single operator to load and unload the drilling rig.

@The patented float clamp can effectively prolong the service life of the drilling shaft.

@With multiple safety protection functions and the alarming system on the engine and hydraulic parameter, the operator and the machine are safely protected.

Model		XZ680
Engine model		CUMMINS
Rated engine power	kW	250
Max. pul l/ drill force	kN	680/680
Max. torque of power head	N.m	27000
Revs of power head	r/min	0-100
Max. reaming bore diameter	mm	?1000
Length of drill shaft (single)	m	6
Diameter of drill shaft	mm	?102
Drill angle	°	10-18
Max. slurry flow	L/min	600
Max. slurry pressure	bar	100
Machine weight	kg	25000
Dimension (L×W×H)	mm	11000×2800×3300
