Tractor Truck with Concrete Tank Semi-Trailer

Live chat with Seller

If you want to live chat with Seller ,Please - LOGIN to View Links.

Tractor Truck with Concrete Tank Semi-Trailer

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Set)	Unit Price
1.0	US $ 21980/

Price:US $21980.0 / Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T

Price Valid Time:From Apr 23, 2015 To Jul 23, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:LHY9403GFLB

Type:Semi-Trailer

Load Capacity:50t

Certification:CCC

Wheel Base:8000-9000mm

Tread:1820mm

Grade:Heavy Duty

Towing Pin Material:Carbon Steel

Impeller Type:Closed Type

Hook Type:Single

Universal Joint Type:Flexible Universal Joint

Brake Pad Material:Ceramic

Towing Pin Type:Cross Type

Towing Pin Diameter:90mm

Differential Gear Type:Gear Type

Independent Suspension Type:Cross Arm Type

Connecting Type:Semi-trailer

Shape:Flatbed

Axle Number:3

Tire Number:12

Self-dumping:Not Self-dumping

ABS Anti-lock Braking System:No ABS Anti-lock Braking System

Material:Steel

Condition:New

Scale:Heavy Duty

Components:Trailer Suspension

Export Markets:Global

Additional Info.

Trademark:CIMC

Packing:Nude Packing

Standard:Euro 2 and 3 Standard

Origin:Shandong, China

Production Capacity:10000 Units/Month

Product Description

Bulk cement tanker semi trailer, is specially designed for bulk powder cargo transportation, like cement, corn, wheet, and other grains. Round cylinder design is good for fast-speed discharging(3-4 discharging outlets) and container transportation ( tanker body and chassis can be seperately loaded into contaier and conncetec by bolts and nuts).

Capacity: 52CBM
Manhole Cover: Alluminum manhole cover
Air compressor: 9.5CBM air compressor
Engine: Disel engine or electrical motor-optional

Chassis: Special designed chassis for heavy duty and extra durability
Axle: German style(BPW, L1, etc) or American type(Fuwa).
Suspension: Mechanical suspension or air suspension-upon requirement
Landing Gear: 28T, two speeds.
King Pin: 2"or 3.5" bolt-in King pin

Item No.	ZCZ9400GFLHJB	Batch	240
Brand	CIMC	Type	Bulk cement semi-trailer
Rated weight	30000,30960	Total Weight(kg)	39710
Curb weight(kg)	9710,8750	Axles' Quantity	3
Axle base(mm)	5250+1310+1310	Axle load	-/7990/7960/7940
Q'ty of the steel plate spring	-/10/10/10,-/4/4/4,-/7/7/7	Tyre Quantity	6
Tyre size	425/65R22.5	Approach/Departure angle	-/23
Front/rear suspension(mm)	-/1555	Front wheel base	-
Rear Wheel base(mm)	2000/2000/2000	Vin No.	LZ1B43GE×××××××××
Overall length	'10975,10025	Overall wide	2500
Overall height	3900	Max loading of the saddle	15820
Remark	Have been installed the side and rear reflective logos.Overall outside dimensions of tank body:the diameter for the front end:1958mm;the diameter for the rear end:2408mm;Straight length of tank body:8870mm(not including both ends),Effective volume:44CBM,Transport medium:dry coal ash,density:710kgs/CBM.The front Diesel engine and air compressor is optional,The overall length when no installed will be 10025mm.The wheel protective plate is optional,Manufacturer/Model of the ABS system:Guangzhou branch secret automobile brake development center/CM-0331000;rear protective section height/width/terrain clearance:140mm/70mm/540mm,Side and rear protective material/connection:Q345/rear protective welding/side protective bolt connection.
