The Cimc LNG Tank Semi Trailer 52000L LNG Trailer

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 28000/ Piece

Price:US $28000.0 / Piece

Trade Terms: FOB, CIF, DAP

Payment Terms: L/C, T/T

Price Valid Time:From Aug 01, 2014 To Nov 01, 2014

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:JC9400GDY

Type:Semi-Trailer

Colour:White

Material:Stainless Steel

Scale:Heavy Duty

Certification:ISO

Components:Tralier

Load Capacity:50T

Export Markets:Global

Additional Info.

Trademark:CIMC

Packing:Nude

Standard:TS16494

Origin:China

HS Code:897642

Production Capacity:10000PCS/Year

Product Description

Tank volume: 52000L
LNG Tanker Truck with 3C and ISO9001 Certificate,
Ordnance Industry Scie
30 years of production experienc

Basic parameter

Machine weight (Kg)
19720
Rated contained mass (Kg)
20280

Gross Vehicles Weight (Kg)
40000
External Dimensions

(Length× Width× Height)
13000x2500x3990

Water capacity
52000 L

Unit volume filling weight(KG/L)
0.38

Design temperature(° C)
-196
Design pressure
0.7mpa

Applicable shipping medium
Liquefied natural gas(LNG)
Maximum allowable work pressure MPa
? 0.7

Inside tank

Material
0Cr18Ni9/SUS304
Tanks shell material
16MnR/Q235-B

Adiabatic way
Vacuum \ multi-layer adiabatic
Adiabatic materials

Aluminum foil, adiabatic paper

The relief valve is opened pressure(Mpa)
0.74~0.77

Main configuration

Items
Data
Items
Data

(BPW 13t)Shaft
3 set
Tire (11.00R20)
12+1 set

Traction pin
1 set
Spare tire leg leveler
2 set

Steel mechanical damping system
1 set
Gas transmission brake system
1 set

24V circuit system
1 set
ABS
1 set

Outrigger
1 set
Basic hand tool
1 set

Loading and unloading valve
1 set
Loading and unloading hose
1 set

Liquidometer
1 set
Relief valve
2 set

Pressure instructions thermometer
1 set
Fire extinguisher
2 unit

Pressure gauge
1 set
Anti-static drag ground
1 unit

Valve box
1 unit
Toolbox
1 unit

Description of products

This kind of vehicles is used to transport liquefied natural gas (LNG) specially. It has been applied in liquefied petroleum gas transportation already for nearly 30 years. It has reasonable design, mature technology, safe and reliable. The number of the products we provided to the Chinese and foreign users has been more than 50, 00. The design, manufacturing and inspection of our products are in accordance with the national standards: GB150, GB1589, this standards and international dangerous road transport standards is equal. We can design different size tanks for users to correspond with local vehicles loaded weight standard.

basic parameter
Machine weight (Kg)		19720	Rated contained mass (Kg)	20280
Gross Vehicles Weight (Kg)		40000	External Dimensions (length×width×height)	13000x2500x3990
Water capacity		52000 L	Unit volume filling weight(KG/L)	0.38
Design temperature ( °C)		-196	Design pressure	0.7mpa
Applicable shipping medium		Liquefied natural gas(LNG)	Maximum allowable work pressure MPa	?0.7
Inside tank material		0Cr18Ni9/SUS304	Tanks shell material	16MnR/Q235-B
Adiabatic way		Vacuum \ multi-layer adiabatic	Adiabatic materials	Aluminum foil, adiabatic paper
The relief valve is opened pressure(Mpa)		0.74~0.77
Main configuration
Items	Data		Items	Data
(BPW 13t)Shaft	3 set		Tire (11.00R20)	12+1 set
Traction pin	1 set		Spare tire leg leveler	2 set
Steel mechanical damping system	1 set		Gas transmission brake system	1 set
24V circuit system	1 set		ABS	1 set
outrigger	1 set		basic hand tool	1 set
Loading and unloading valve	1 set		loading and unloading hose	1 set
liquidometer	1 set		Relief valve	2 set
Pressure instructions thermometer	1 set		Fire extinguisher	2 unit
Pressure gauge	1 set		Anti-static drag ground	1 unit
Valve box	1 unit		toolbox	1 unit
description of products
This kind of vehicles is used to transport liquefied natural gas (LNG) specially.It has been applied in liquefied petroleum gas transportation already for nearly 30 years.It has reasonable design, mature technology, safe and reliable. The number of the products we provided to the Chinese and foreign users has been more than 50,00.The design, manufacturing and inspection of our products are in accordance with the national standards:GB150, GB1589, this standards and international dangerous road transport standards is equal . We can design different size tanks for users to correspond with local vehicles loaded weight standard.
