Stainless Steel 304 Flange Screw Flange Bolt

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:$0.07 - $0.09 / Piece

Min. Order (Pieces)	Unit Price
10000.0	US $ 0.09/ Piece
100000.0	US $ 0.07/ Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T, Western Union

Price Valid Time:From Jun 12, 2015 To Dec 31, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:LKIV

Material:Stainless Steel, Alloy Steel, Steel

Type:Hexagon Head With Flange

Connection:Common Bolt

Head Style:Hexagonal

Standard:DIN, GB, ANSI, BSW

Sample:Free

Market:Global

Additional Info.

Trademark:LK

Packing:Bulk Packing, Small Box

Standard:DIN, ANSI, ISO and Non-Standard

Origin:China

HS Code:7318

Production Capacity:500 Ton/Month

Product Description

Stainless Steel Flange Screw Flange Bolt
1> Decription: Stainless Steel Flange Screw Flange Bolt
2> Material: Stainless Steel, Alloy Steel, Steel
3> Surface: Passivation, Zinc plated in chromium and RoHS,
4> Size: M6(1/4") upto M16(5/8")
5> Length: Up to 300mm
6> Mechanical Properties: Class4.8, 8.8, 10.9 Grade 2, 5; A2-70, A4-70
7> Packing: Bulk packing and small box packing

The main products for bolts include Hex. Bolt, Hex. Socket cap screw, Allen Screw, Lag bolt(Coach screw), Carriage bolt, Hex. Flange bolt, Thread Rod, Square Bolt, Hex. Bolt with nuts and some special bolt per the drawing from the cilent.

Please feel free to contact us if you are interesting our products. We are strongly believe will guarantee you the best quality and service for our more than 30 years professional experience.

Technical Delivery Conditions
Material		Steel	Stainless steel
General requirements		As specified in DIN 267 part 1
Thread	Tolerance	6g
	Standard	DIN13 Part 12 & 15
Mechanical properties	Property class	8.8 10.9 12.9	A2-70 A4-70


	Standard	ISO 898 Part 1	DIN267 Part 11
Limit deviations geometrical tolerance	Product grade	A

	Standard	ISO 4759 Part 1
Surface finish		Blackened	Bright
		DIN267 Part 2 shall apply with regard to surface roughness
		DIN267 Part 19 shall apply with regard to permissible surface discontinuities
		DIN267 Part 9 shall apply with regard to electropiating
		DIN267 Part 10 shall apply with regard to hot dip galvanizing
Acceptance inspection		DIN267 Part 5 shall apply with regard to acceptance inspection
