Performance:
1. The first "double u shape move gear brake" technology, safe, reliable, and leading domestic.
2. The braking system adopts special materials, special craft processing, corrosion resistance, impact resistance, resistance to wear.
3. A integrated aluminum alloy shell, light weight, corrosion resistance, without disassembly.
4. Two end all adopt to take off the hook, safe and reliable.
5. Provide a wide range of activities of the distance radius, do not need to change the suspension point in the process of work.
6. Precise calculation of wheel, brake gear modulus, the wire rope pulling speed 1 m/s, or within 0.2 meters braking system action, ensure the personnel safety.
7. Air nylon material, special weaving process manufacturing wire, flame retardant, high temperature resistant, anti-aging, safe and reliable.
8. The unique exterior surface treatment technology, beautiful appearance, easy.
This product can be widely used in electric power, building, ships, telecommunications, pharmaceutical, Bridges and other places of high operation.
Use objects fall velocity difference for self-control, high hanging low. Just need to when using nylon rope crossing above the solid blunt edge on the structure of iron hook the nylon cord into the "n" ring, the iron hook on the rope into the seat belt can be used in a half circle. In the use of radius, does not need to change the suspension point. Normal use, safety rope will free expansion with the human body. Institutions under the action of inside the device, half tension, make the operator without caring touch. One thousand falls, safety rope pulling speed obviously accelerated, locking system will automatically lock in the vessel. Make the safety rope to pull out the distance not more than 0.2 meters, the impact is less than 2949 n, there is no harm to stumble personnel. Lift the load automatically return to work. After work safety rope will be automatically recycled into device, easy to carry. Locking stability, high safety coefficient, good reliability, and effectively solve the tilt because of too much homework down swing amplitude and impact other objects and cause of the accident.
This control system USES special steel products, and through special processing, qualitative light, wear-resisting, corrosion resistance, impact resistance, shell adopts aluminium alloy, qualitative light, not aging.
Choose aviation wire rope safety rope. Sling, seat belts, are dealing with flame retardant, resistance to high temperature of 200, and form a complete set of the factory, the purchase and play.
Use method and matters needing attention:
1, this product must be high hung low, should be hung over the users when using solid blunt the edge of the structure.
2, before the use of this product, should do check the safety rope, appearance, and tried to lock 2 ~ 3 times (try locking methods: Pull the safety rope to normal speed should be a "click", "click" sound, forcibly jerked safety rope, should be able to lock up. Let go when the safety rope should return to the device can automatically, such as safety rope failed to completely recycle, only slightly pull out some safety rope). If there is any abnormal or stop using, return to the factory warranty period changing.
3, the use of this product, when tilt, slope, in principle, no more than 30, more than 30 must consider whether the impact to the surrounding objects.
4, this product has key parts do wear-resisting, corrosion resistance and other special processing, and the strict debugging, when using do not need to add lubricant.
5, the product safety rope is forbidden to use secure. It is forbidden to remove the modification. And should be kept in dry, little dust.
