Sinotruk HOWO 290HP 6X4 Container Tractor Head

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:

Min. order:1 Piece

Trade Terms:FOB, CFR, CIF

Payment Terms:L/C, T/T

Trademark:SNIOTRUK-HOWO 7

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:ZZ4257N3247C1

Transmission Type:Manual

Power:Diesel

Load Capacity:21-30t

Emission Standard:Euro 3

Drive Wheel:6×4

Seats:?5

Horsepower:251-350hp

Engine Capacity:?8L

Tire Type:Inner Tube

Tire Certification:ISO

Tire Design:Radial

Condition:New

Truck Type:Tractor Truck

Export Markets:South America, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia

Additional Info.

Trademark:SNIOTRUK-HOWO 7

Packing:Nude Packing

Origin:Shandong, China

Production Capacity:6000units/Month

Product Description

SINOTRUK HOWO 290HP 6X4 container tractor head

Traction type: 6X4
Driving type: LHD (RHD is option)
Cabin: HOWO cab HW79 ( high head, high-roof, double sleeper bed, A/C)

Engine
Engine brand: SINOTRUK BRAND
Engine model: WD615.50 290HP Euro II
Engine type: 6-cylinder in line, 4-stroke, water-cooled, turbocharged, air-to-air intercooled, direct injection
Displacement: 9.726 liters
Max. Output: 290HP@2200rpm
Max torque: 1160NM@1100-1600rpm
Bore/Stroke (mm): 126/130
Mean Position Speed: 9.53m/s
Compression ratio: 15.5: 1
Specific fuel consumption: 198g/Kwh

Gear box
Gear box: HW13710

Clutch:
Clutch: ? 430 pull-type diaphragm clutch

Steering:
Steering: ZF8098 integral type power-steering

Tyre
Tyre: 12.00-00
No. Of tyre: 10+1spare

Front axle: HOWO front axle 7ton
Rear axle: HW1697

Spring: 9/12
Fuel tank capacity (L): 400 Aluminium Alloy Tank
Max. Speed (km/h): 90
Kerb. Mass: 8800kg
Total mass: 25000kg
Max towing load: 40000kg
Wheel base (mm): 3225+1350
Front overhang (mm): 1500
Rear overhang (mm): 725
Front track (mm): 2022
Rear track (mm): 1830
Approach angle: 16 degree
Departure angle: 70 degree
Dimension (mm): 6800x2496x2958
5th wheel: 2.0" (3.5" is option)

Name	Sinotruk HOWO 290HP 6x4 Container Tractor Head
Model	ZZ4257N3247C1 LHD
Brand	SINOTRUK-HOWO
Overall Dimensions(mm)	About 6800x2496x 2958,3718,3563,3668
Curb weight(kg)	About 8850
Loading Capacity (kg)	About 40000
G.V.W.(kg)	About 25000
Engine	371hp
Emission	EUROII
Transmission	HW19710, 10 forwards, 2 reverses
Rear Axle	ST13
Front Axle	HF7
Steering System	ZF8098
Tyre	295/80R22.5
Cab	HW76, onesleeper, with air condition
Wheel Base(mm)	3225+1350,3200+1400
Approaching/Departuring Angle( ° )	16/70
Front/Rear Overhang(mm)	1500/725,700
Max Speed(km/h)	90,102
Other	ABS, Saddle
