Sinotruk 6X4 Steyr Tractor Truck Tractor Horse

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 30000.0-50000.0/ Piece

Price:$30000.0 - $50000.0 / Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T

Price Valid Time:From Sep 15, 2014 To Dec 15, 2014

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:ZZ

Transmission Type:Manual

Power:Diesel

Load Capacity:21-30t

Emission Standard:Euro 2

Drive Wheel:6×4

Seats:?5

Horsepower:351-450hp

Engine Capacity:?8L

Tire Type:as Customer?s Requirement

Tire Certification:ISO

Tire Design:Radial

Condition:New

Truck Type:Tractor Truck

Export Markets:Global

Additional Info.

Trademark:Steyr

Packing:Nude

Standard:6*4

Origin:China

HS Code:8701901990

Production Capacity:200units/Month

Product Description

1. Cabin: Driving type 6x4 LHD
Steyr Standard cab, with two bunks, 70° Hydraulically tillable to the front as attached photo for ref.
2. Overall dimensions (L x W x H)mm: 6800x2496x3668
Wheel base (mm) 3200+1400
Wheel track (front/rear) (mm) 2022/1830
Approach/Departure angle(° ) 16/20
3. Weight in KGS: Tare Weight 9210
Hauling Capacity 39800
Front axles loading capacity 1x8000
Rear axles loading capacity 2x16000
4. Max. Driving speed(km/h) 95
5. Engine Brand Sinotruk
Model Steyr WD615.47
Type 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
Horse Power(HP) 371HP
Emission standard Euro II
6. Gearbox HW9, 9 forwards & 1 reverse
7. Clutch Reinforced diaphragm clutch, diameter 430mm
8. Steering Gear ZF 8098, power steering, hydraulic steering with power assistance
9. Fuel tank (L) 400
10. Tire: 12.00-20 nylon tire, 12.00R20 All steel radial tire is available, 10 pieces
11. Brakes Service brake: Dual circuit compressed air brake
Parking brake: (emergency brake): Spring energy, compressed air operating on rear wheels
Auxiliary brake: Engine exhaust valve brake

Representative vehicle models		ZZ4257M3241V
CAB	Model	HW79
	Type	High cab
Engine	Model	WD615.87
	Rated power kW/rpm	213/2200
	Maximum torque Nm/rpm	1160/1100-1600
	Displacement L	9.726
Clutch		? 430 Diaphragm spring clutch
Transmission		China National heavy duty truck HW Series
Front axle		HF7
Driving axle		HW1697
Steering system		ZF8098
Electrical system		Voltage: 24V: 2 × 12V/165Ah
Tire		12.00-20 Or11.00-20
Fuel tank capacity L		400
Curb weight kg		9210
Total mass kg		25000
Trailer mass kg		32400
Saddle allows loading weight kg		15660
Overall dimensions (l x w x h) mm		6800x2496x3563
Wheel base mm		3200+1400
Front suspension / Rear suspension mm		1500/725
Track width (front / After) mm		2022/1850
Minimum ground clearance mm		267
Approach angle / Angle of departure °		16/70
Maximum speed km/h		102
Maximum grade ability %		20
Minimum turning diameter m		15
Saddle land ground clearance ( Empty / full ) mm		1360/1326
Qian / Slewing RADIUS after mm		2790/2230
Towing pin specification		50#( 2 In)
