Engine |
Made: SINOTRUK |
|
|
|
|
Diesel 4-stroke direct injection diesel engine |
|
|
|
Engine model: WD615.69, Euro II emission standard |
|
|
|
6-cylinder in-line with water cooling, turbo-charging and intercooling |
|
|
Maximum output: 336 hp (247 Kw) at 2200 rpm |
|
|
|
Number of cylinder: 6 |
|
|
|
|
Displacement: 9.726 l |
|
|
|
|
Bore: 126 mm |
|
|
|
|
Stroke: 130 mm |
|
|
|
|
Compression ratio: 29.8 hp/l |
|
|
|
|
Specific fuel consumption: 195 g/kWh |
|
|
|
Engine oil filling quantity: 23 l |
|
|
|
|
Cooling system filling quantity (long-term filling): 40 l |
|
|
|
Thermostat with 71 degree opening begin |
|
|
|
Single cylinder air compressor |
|
|
|
|
Rigid fan |
|
|
|
|
|
Transmission |
HW15710, 10 speeds forward and 2 reverse |
|
|
|
Fuller technology |
|
|
|
|
|
Propeller Shaft |
Double universal joint propeller shaft with gear-shaped coupling flange |
|
|
Front Axle |
Steering with double T-cross section beam |
|
|
|
Rear Axle |
Pressed axle housing, central single reduction |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Chassis |
Frame: U-profile parallel ladder frame with section of 350x80x10 mm and reinforced subframe, all cold riveted cross members |
|
Front suspension: 9 semi-elliptic leaf springs with hydraulic telescopic double-action shock absorbers and stabilizer |
|
Rear suspension: 12 leaf semi-elliptic springs with bogie springs |
|
|
Aluminium fuel tank: 300 L capacity with locking fuel cap, fitted to the off side of the chassis |
|
|
|
|
|
|
|
|
Steering |
ZF power steering, modol ZF8098, hydraulic steering with power assitance |
|
|
|
|
|
|
|
|
Brakes |
Service brake: dual circuit compressed air brake |
|
|
|
Parking brake(emergency brake), spring energy, compressed air operating on rear wheels |
|
|
Auxiliary brake: engine exhaust brake |
|
|
|
ABS |
|
|
|
|
|
Tyre |
Tyre: 12.00R20 |
|
|
|
|
|
Driver' s Cab |
Volve Cab, (2 seats and 1 bed)all steal forward control, 2-arm windscreen wiper system with three speed, laminated windscreen with |
|
casted-in ratio aerial, hydraulically damped adjustable driver' s seat, with heating and ventilating system, exterior sun visor, safety belts, |
|
adjustable steering wheel, air horn, air conditioner, with transverse stabilizer |
|
|
|
|
|
|
|
|
Electrics |
Operating voltage: 24 V, negative grounded |
|
|
|
Starter: 24 V, 5.4 Kw |
|
|
|
|
Alternator: 3-phase, 28 V, 1500 W |
|
|
|
Batteries: 2 x 12 V, 165 Ah |
|
|
|
|
Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light |
|
|
Instrument Panel |
Active check central controllor with indicators, with this integral instrument the daily manual checks on the vehicle and combined indicators |
|
of compressed air pressure, coolant temperature, engine oil pressure and battery charging |
|
|
Dimensions mm |
Wheel base |
|
|
3420+1350 |
|
Front wheel track |
|
|
|
1830 |
|
Rear wheel track |
|
|
1830 |
|
Front overhang |
|
|
|
1500 |
|
Rear overhang |
|
|
|
1670 |
|
Overall length |
|
|
|
8300 |
|
Overall width |
|
|
|
2500 |
|
Overall height |
|
|
|
3400 |
|
Dimension of the rear dump body |
|
16m3 |
|
5200*2300*1400 |
|
Weight kg |
Gross vehicle weight |
|
|
|
25000 |
|
Rated loading capacity |
|
|
|
32000 |
|
Front axle loading capacity |
|
|
|
9000 |
|
Rear axle loading capacity |
|
|
|
2*16000 |
|
Performance |
Maximum driving speed (km/h) |
|
|
|
75 |
|
Maximum gradeability (%) |
|
|
|
40 |
|
Minimum ground clearance (mm) |
|
|
|
314 |
|
Minimum turning circle (m) |
|
|
|
20 |
|
Fuel consumption (l/100 km) |
|
|
|
28 |
