Side Board Cargo Transport Semi Trailer (QDT9133)

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:

Min. order:1 Piece

Trade Terms:FOB, CFR, CIF, DDP, DAP, FCA, EXW

Payment Terms:L/C, T/T

Trademark:QT

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:QDT9133

Type:Semi-Trailer

Certification:SGS, ISO/TS16949, ISO, CE

Loading Weight:30T

Shape:Flatbed

Self-dumping:Not Self-dumping

ABS:With ABS

Axle Number:2

Security Initiative Protection Device:With Security Initiative Protection Device

Tire Number:8

Condition:New

Loading Capacity (Kg):10000

Gross Weight (Kg):13155

Dimension (Mm):8600X2492X2424

Inner Board Size(Mm):8450X2300

Material:Steel

Scale:Heavy Duty

Components:Trailer Axles

Load Capacity:10t

Export Markets:Global

Additional Info.

Trademark:QT

Packing:Nude Packing

Standard:SGS, CE

Origin:Qingdao, Shandong, China

HS Code:8716

Production Capacity:12, 000/Year

Product Description

Board Cargo Semi-Trailer (QDT9131)

Model: QDT9131

Tare Weight (kg): 3155

Loading Capacity (kg): 10000

Gross Weight (kg): 13155

Dimension (mm): 8600X2492X2424

Inner Board Size(mm): 8450X2300

Wheel Base(mm): 6000

Overhang(Front/Rear)(mm): /1800

Wheel Specification: 10.00-20 14PR

Wheel Track(mm): 1800

Approach Angle/Departure Angle(° ): 15

Plate Spring Quantity: -6

Assembly Type	QDT9131
Tire Weight (kg)	3155
Normal Load (kg)	10000
Gross Weight (kg)	13155
Dimension (mm)	8600x2492x2424
Inner Board Size(mm)	8450x2300x
Wheel Base(mm)	6000
Overhang(Front/Rear)(mm)	/1800
Wheel Specification	10.00-20 14PR
Wheel Track(mm)	1800
Approach Angle/Departure Angle(°)	15
Plate Spring Quantity	-6

Company Presentation

Qingdao Zhongqi Special Automobiles Co., Ltd., one of the most important entities of Qingte Group Co., Ltd., is a joint corporate enterprise set up by Qingte Group Co., Ltd. and China Auto Industry Import & Export Corporation. Established in 1992 with registered capital of RMB 100 million yuan and 130 thousand sq.m. of floor space, Qingdao Zhongqi Special Automobiles Co., Ltd. now have reached an annual Production Capacity of 10 thousand sets of various kinds of Special Vehicles.

Basing on technique breakthrough of Chassis and Special Device, we have obtained great development on product series of Hydraulic Aerial Platform Vehicle, Special Operation Vehicle, Municipal Duty Vehicle, Construction Operation Vehicle, Heavy-duty Road Transportation Truck, City Cleaning Truck, and other high grade products including Military Vehicle, Airport Tractor and Oil Transportation Truck, gradually forming our Qingte feature which shows an advanced level both in domestic and internationally. It is worth mentioning that the Hydraulic Aerial Platform Hot-line Work Vehicle, cooperative developed products with Altec, USA, have always been world first class and the best in domestic.

Our Hydraulic Aerial Platform Hot-line Work Vehicle series and Multi-function Poling Machine, adopting optimal configuration from Altec, could satisfy wide ranges of demand from power sector, communication sector and city construction, with its working height from 11m to 25m and isolation voltage from 46KV to 220KV. Qingte-Altec Products have passed the performance test processed by the State Power Corporation assigning institution, Wuhan High Pressure Research Institution(WHHPRI), with all of its technical index reaching the original design standard. After its test, the series was highly recommended by the institution.

Qingdao Zhongqi Special Automobiles Co., Ltd. has taken the leading in obtaining ISO9001:2000 Certification, ISO14000 Environment Management System Certification, OHSMS18000, CCC and the National AAAA Level Standardization Good Behavior Enterprise Confirmation, establishing a thorough quality management system. Qingte Group Co., Ltd. was identified 2012 National Technology Innovation Demonstration Enterprise. With a national level enterprise technical center, containing its high technical level and development capabilities, Qingte Group now have an independent capacity of developing various kinds of special vehicles and parts
