Specifications |
|
Item |
Specification |
|
Chipset |
H.264 image compression chip |
|
Sensor device |
Forward facing lens:720P CMOS Sensor |
|
Backward facing lens:VGA CMOS Sensor |
View Angle
|
Outside vehicle approx : 120 degree |
|
Inside vehicle approx : 170 degree |
Voltage
|
Please use 5V±5%, 1A Cigarette lighter adapter. The
machine needs 4.7v to start. |
|
Operating temperature |
-15°C~+55°C (Inside Vehicle). |
Storage Device
|
Micro SD Card (4G/8G/16G/32G) of Silicon Power and
Transcend recommend. 4GB/Class 10 or above specification is available |
|
Recording Frame |
Forward facing lens: 1280x720; Highest resolution:
30fps/25fps (NTSC/PAL) |
Backward facing lens: 640x480; Highest resolution:
Frame 15fps/15fps (NTSC/PAL) |
Auto record when power up system; backward facing
lens can be closed by setting of software. |
|
Recording Content |
Date, time, image, sound, G-sensor data, GPS data. |
|
Recording Format |
Specific format for software player. |
Microphone
|
Build-in high sensitivity of single microphone for
automatic voice adjustment. |
|
Time setup |
Auto-calibrating by GPS signals. If GPS is not available, the built-in clock will be used. |
|
G-Sensor |
Internal 3D G-Sensor. |
Out Device
|
a) TV-Out (1 Vp-p composite video output, 75 ohms),
Video Output format: NTSC / PAL alternative.
(b) Force Record Button: For emergency recording.
Gleams in night time.
(c) Red light: Recording indicator. In emergency
recording, it flashes more frequently.
(d) Green light
Flashing: Searching GPS signals.
Light on : GPS positioning ready
(e) External hole to connect GPS Mouse
Remark: When IR turns on, the LED light will be
dimmer. |
|
Description |
(a) The GPS positioning speed will be influenced by
solar film of the front windshield, weather or other
environment factors.
(b) Starting and closing time of infra red will be subject
to light intensity, the installation location, front
windshield and other factors ...
Description (c) Day and night mode having delay mechanism for
about 30 seconds. Night mode will be priority when
power on.
(d) Memory card formatted by using the playback
software, windows will recognize the remaining
capacity about 80MB for copying the player software
to memory card. |
|
Important Notice |
(a) The current consumption of the machine over
standard USB hole (output 500mA). When connect
with PC power supply, it's better to buy another
Important
power cable with two holes for portable hard drive.
Notice
(b) Machine must be installed in the area that wipe can
be reached to ensure the clarity of recording video.
(c) Please do not plug the power in both micro-USB soctets,The machine might be damaged.
(d) If not use the plaer to format memory card,the machine will to force to format entire memory card and then start recording.
(e) It better not crossing the top of the machine and the left side of the GPS.We suggest to put the cables via the right side of the VVR and then connect to the ceiling to get better GPS signal.
(f) Initial screen and live view screen may change due to software update or revision without notice.
(g) The machine itself has a distinction between NTSC and PAL.Video output to the monitor with correspoding screen sytem.
(h) Interior lens adopt ultra-wide-angle lens.There will be sight cover corner phenomenon at the corner edge.
(i)Memory card has the number of reading and life issue.please check and use the computer to play video regularly in order to make sure the memory card can read and write properly. |
|
Accessories |
Standard: (a) 5V cigarette power adaptor
(b) USB card reader
(c) 4 pings,3.5 inch headphone jack to RCA output cable.
(d) Suction cup bracket.
(e) Bracket holder.
(f) Remote controller.
(g) Product CD.
(h) Quick Guide |
Optional: (a) Micro SD Card (4G/8G/16G/32G)
(b) External GPS mouse (4P Phonejack connect ) |
