M20 GPS Tracking Device with GPS Antenna Cut Alert

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 300/ Bag

Price:US $300.0 / Bag

Trade Terms: FOB, CFR, CIF, EXW

Payment Terms: T/T, Paypal, Money Gram, Western Union

Price Valid Time:From Jun 09, 2014 To Jul 07, 2014

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:BSJ-M20

Function:Remote Control to Open the Trunk, Anti-theft Warning, GSM Network Remote Real-time Monitoring, Mute Anti-theft, Automatically Unlock when Get Close

Type:GSM

Size of The Main Unit:110*80*25mm

Weight of The Main Unit:170g

Input Voltage:DC 9V to 36V

Backup Battery:3000mAh/3.7V

Power Consumption:65mA

Operating Temperature:-20 to 80 Centigrade

Humidity:5% to 95%

Lead Time of Backup Battery:10 Hours in Normal Mode

Data Logger Memory:4MB

Sensor:Inbuilt Motion Sensor

Export Markets:Global

Additional Info.

Trademark:BSJ/Customized brand is accepted

Packing:Gift Box/Netural Box

Standard:ISO9001; CE; Rohs; CCC;

Origin:Shenzhen, China.

HS Code:85311010

Production Capacity:2, 000, 000PCS/Week

Product Description

1. M20 GPS tracking device with GPS Antenna Cut alert

GPS tracking device M20 with long-lasting battery life and 20 ports to expand functions for automotive security motion sensor for shake alarm and power saving is designed for car, truck and fleet management. It is a new product based on 900/1800/850/1900MHZ for worldwide market. It is a mulstiple gps tracker and car alarm device. Support upgrade firmware in air for free.

2. Applications of M20 GPS tracking device with GPS Antenna Cut alert
Vehicle Real Time Tracking
Vehicle Data Warehouse
Location Based Service
Car Security/Anti-Hijack
Fleet Management

3. Features of M20 GPS tracking device with GPS Antenna Cut alert
U-blox GPS and Quad Band GSM 850/900/1800/1900Mhz
Track by SMS/GPRS (TCP/UDP)
Track on Demand
Track by Time Interval
Track on Mobile Phone
Inbuilt Motion Sensor
3, 000mAh Internal Backup Battery
Mileage report
Wiretapping
Power low/lost alert
Towing alert
SOS alert
Geo-fence alert
GPS Antenna Cut alert
20 ports(5 digital inputs; 4 digital outputs; 4 analog inputs; 2 audio outputs; 2 audio inputs)

4. Accessories of M20 GPS tracking device with GPS Antenna Cut alert

M20 GPS tracker
GPS antenna
GSM antenna
Microphone
I/O cable
Panic button
USB cable

5. Optional accessories of M20 GPS tracking device with GPS Antenna Cut alert

Fuel sensor
Temperature sensor
Relay

Items	Parameter
Dimension	110mm80mm25mm
Weight	170g
Input Voltage	DC 9V~36V/1.5A
Back-up Battery	3000mAh/3.7V
Power consumption	65mA standby current
Operating temperature	-20~80 Centigrade
Humidity	5%~95%
Work Time	10 hours in normal mode
LED	3 LED lights to show GPS, GSM and Power
Button	1 SOS and 1 power on/off
Microphone	1
Speaker	1
Flash memory	4MB
Sensor	Built in motion sensor
GSM frequency	GSM 850/900/1800/1900MHz
GPS chip	U-blox
GPS sensitivity	-159dB
Positioning accuracy	10 meters
I/O ports	5 digital inputs; 4 digital outputs; 2 analog inputs; 2 audio outputs; 2 audio inputs.
USB port	1 USB for configuration, updating firmware and detecting logs
