| Overall Dimensions |
|
| Length (mm) | 13670 |
| Width (mm) | 3860 |
| Height (mm) | 2550 |
| Interior height (mm) | 1995 |
| Wheel base (mm) | 6250+1470 |
| Track Front/Rear (mm) | 2020/ 1860/2066 |
| Front/Rear Overhang (mm) | 2620/3330 |
| Min. Ground clearance | 192 |
| Approach/Departure Angle ( o ) | 8.5/9 |
| Brake distance (v=30km/h fully loaded) | ? 10 |
| Fuel consumption (L/100km) | 26 (limited conditions) |
| Kerb weight (kg) | 16000 |
| Front/Rear Axle (kg) | 4400/7300/4300 |
| Gross vehicle weight (kg) | 22000 |
| Front/Rear Axle (kg) (loaded) | 5500/10500/6000 |
| Max. Speed (km/h) | 125 |
| Max. Grade ability (%) | 30 |
| Min. turning diameter (m) | ? 24 |
| Fuel Tank Capacity (L) | 400 |
| Luggage compartment (m 3 ) | 8.4 |
| Engine |
|
| Arrangement of Engine | Six cylinders, water coolant, direct injection, turbocharged, inter-cooling. |
| Model | CUMMINS L360 20 |
| Displacement (L) | 8.9 |
| Bore X stroke (mm) | 114 × 144.5 |
| Compression Ratio | 16.6:1 |
| Max. Output (kw/rpm) | 264/2200 |
| Max. Torque (N.m/rpm) | 1480/1300 |
| Type of Fuel | Diesel |
| Emission Standard | Euro II |
| Chassis |
|
| Clutch | SACHS MFZ430, Single dry type, hydraulic remote control, with air assistance |
| Gearbox | ZF S6160, 6-gear transmission with synchronizer. Triple flexible shaft with remote operation. |
| Front axle | MERITOR, 6.5T. Disc brake |
| Rear axle | MERITOR, 13T. Disc brake |
| Supporting axle | MERITOR Disc brake |
| Retarder | TELMA retarder |
| Suspension system | 8 air-bag suspension with bi-directional hydraulic shock absorber and stabilizer. |
| ABS/ASR, adjust arm | WABCO ABS, ASR |
| Steering gear | ZF 8098 Integral power steering.Adjustable steering wheel |
| Tire | 8+1 , 295/80R22.5, tubelesstire |
| Braking system | Dual-circuit air braking; air cut-off parking braking. WABCO ABS, WABCO air dryer |
| Other | Flee guard air filter, front/rear hook, 16T jack |
| Electric system | 24V single wire; negative ground |
| Starter | 24V, electromagnetic operation |
| Battery/Alternator | Two /140A+150A |
| Body |
|
| Body structure | Semi-integral body; Pre-stress stretched panel skin; full metal panel, sunken aisle. |
| Inner trimming | Soft interior trimming, Integral A/C channel with reading lamp, hang-type curtain for side window |
| Door and door pump | Front pneumatic out-swing door; aluminum up-opening luggage compartment door. |
| Windows | Upper fixed low sliding windows |
| Seat | 57+1+1 adjustable luxurious seats |
| Seat accessories | Adjustable arm, sundries bag, safety belt for passenger seats |
| Air-conditioning system | top mounted A/C (38000 kcal/h). |
| Defrosting system | Natural wind cycle defroster |
| Audio and Visual system | Multi-disc DVD, front 17 inches, middle 15' fixed LCD |
| Rear view system | Electro-driving rabbit ear rear view mirror
Reverse monitor |
| Wiper | Wiper |
| Lamp | integral head lamp, high position brake lamp |
| Service facilities | Electronic clock
Wheel cover
Auto fire extinguisher
Remote control lock for passenger door
Hatch roof
Water machine
Bathroom |
| Others | Metallic color paint; (Electrophoresis Coating for the whole chassis and bus body) |
