Light Weight High Pressure Al-Mg-Mn Alloy Corrugated Roof Plate
Specifications
Al-Mg-Mn Alloy Plate is made of AL3004, an advanced roofing materials, is widely used around the world.
Al-Mg-Mn corrugated steel sheet is the alloy mixed by metallic aluminum, metallic magnesium and metallic manganese. The metallic aluminum, magnesium, manganese alloy is widely used as the material of metal roof for which the building design service life is more than 50 years as it has advantages such as moderate structure strength, weather-proof, waterlogging tolerance and easy be bent, welded and processed, etc.
Al-Mg-Mn roof board, roof primary purline, roof secondary purline, thermal insulating layer, 900 wall inner board, sliding support, moisture barrier and vapor barrier.
Aluminum products have been widely used now in our human life, its scope of application has only second to steel. In the melting process of aluminum to add other metals such as: Manganese, Magnesium, Copper, Zinc, Iron, Tin, etc. To form various series of aluminum alloy.
Thickness Classification:
Thinckness: 0.8mm, 0.9mm, 1.0mm, 1.2mm
Al-Mg-Mn Alloy Plate Classification:
Non-Paint Products: Hammer aluminum, embossed aluminum, pre-passivated aluminum surface panels.
Paint Products: Spray coat, coil coat
By coating types divided into:
Coating type: Polyester, Polyurethane, Polyamide, Modified Silicone, Epoxy, PVDF
Material Properties:
1. Weight: Aluminum density 2.73G/m3, only the steel of 1/3 strength.
2. Itensity: Through melting and heat treatment method can achieve very high strength, even the construction of large aircraft structures.
3. Corrosion Resistance: Outdoor aluminum is durable and reliable construction materials, it has a self-rust function of the surface in the natural environment can form a thin layer of dense oxide layer, to prevent continue in the air oxidation of metal corrosion, but also has a variety of acid corrosion resistance ability.
4. Surface finish and elegant appearance: Can be anodized, electrophoresis, chemical processing, polishing, paint handling.
5. Plasticity is good, and easy to process.
6. Good conductivity: Non-magnetization and low electric spark sensitivity, can avoid electromagnetic interference and reduce the flammability under special circumstances.
7. Links convenience: Aluminum can be riveting, welding, adhesives and other means to connect.
8. Recyclable: High value of aluminum recycling, the cost of long-term use of more economical, in the conservation of natural resources has played a positive role. 100% could be recycled.
