Lead Acid Battery (12v75ah AGM)

Live chat with Seller

If you want to live chat with Seller ,Please - LOGIN to View Links.

Lead Acid Battery (12v75ah AGM)

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
100.0	US $ 65/ Piece

Price:US $65.0 / Piece

Trade Terms: FOB, CFR, CIF, EXW

Payment Terms: L/C, T/T

Price Valid Time:From Nov 07, 2014 To Feb 07, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:GB12-75

Type:Lead-Acid Batteries

Usage:UPS, Lighting, Boat

Nominal Voltage:12V

Discharge Rate:Low Discharge Rate

Shape:Square Battery

Electrolyte:Acid

Installation:Packaged

Rechargeable:Chargeable

Size:260*169*210*217

Color:Black

Voltage:12V

Capacity:75ah

Application:UPS/Solar System/Alarm System

Export Markets:Global

Additional Info.

Trademark:universal power

Packing:Packing in Carton

Standard:1) Nominal voltage: 12v 2) Nominal capacity: 75ah

Origin:China

HS Code:8507200000

Production Capacity:60 20"FCL per month

Product Description

Specifications

Lead Acid Battery (12v75ah AGM)
1size:259*169*208mm
2good price
3agm battery
4MOQ:100pcs

Features & Advantage:

1.Maintenance free

2.High power to weight ratio

3.No memory effect

4.Low self discharge

5.Long service life

6.High discharge rate

7.Wide operating temperature range

8.Competitive prices with reliable quality.

9.Adopting high quality PP plastic for battery case, stronger and heatproof.

10.Plates made of high purity lead 99.994-99.996% dry charged battery

11.High quality AGM separator, pure acid

Application:
Widely Used in:

1.Fire protection ,security uninterruptible power supply, backup power supply

2.Telephone and telecommunication equipment

3.Uninterruptible power supply systems for bank

4.Emergency lighting or small lamp fitting

5.Electric power system

6.Security system

Nominal Voltage		12V
Rated capacity(20 hour rate)		75AH
Dimensions	Length	262�1mm(10.03 inches)
	Width	170�1mm(6.89inches)
	Height	230 �1 mm(9.50inches)
	Total Height	240�1mm(9.66 inches)
Weight Approx		20.5Kg(67.34lbs)

Capacity 25�C		10 hour rate(10.00A, 10.80V)	75.00AH
		5 hour rate(16.00A, 10.50V)	70.00AH
		1 hour rate(60.00A, 9.60V)	60.00AH
Internal Resistance		Full charged Battery at 25 �C (77�F)	4.5m?
Capacity affected by temperature (20 hour rate)		40�C(104�F)	102%
		25�C(77�F)	100%
		0�C(32�F)	85%
		-15�C(5�F)	65%
Self-Discharge at 25�C(77�F)		Capacity after 3 month storage	91%
		Capacity after 6 month storage	82%
		Capacity after 12 month storage	64%
Charge (constant voltage)	Cycle	Initial Charging Currentless than 30.00A Voltage14.40-15.00 V
Charge (constant voltage)	Float	Voltage 13.50-13.80V
Terminal		T10
