IP66 4" Mini High Speed PTZ Doom Camera with FCC and CC Aproved (BQL/KeX39-10)

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:

Min. order:4 Pieces

Trade Terms:FOB, EXW

Payment Terms:L/C, T/T, Western Union

Trademark:OEM / Protruly

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:BQL/KeX39-10

Type:Dome Camera

Sensor:CCD

Speed:High-speed Dome

Technology:Pan / Tilt / Zoom

Feature:Vandal-proof, Mini Size, Waterproof / Weatherproof, High Definition, Awb., WDR ., Mask., Dnr ., Strong Light Inhibition

Horizontal Resolution:480tvl

Image Sensor:1/4" Sony CCD

Signal Model:PAL/NTSC

Lens:Megapixel / 3.8-38mm

Optical Focus and Digital Zoom:10X / 10X

OSD:Full -Screen Chinese / English Menu

Filter:Single Filter, IR Sensor

Export Markets:Global

Additional Info.

Trademark:OEM / Protruly

Standard:CE/FCC/ROHS

Origin:China Shenzhen

HS Code:8525801390

Production Capacity:5000PCS / Week

Product Description

Features:

> Outdoor 6 inch high speed dome camera, Metal double cover.
> Use high quality components, high&minute sub-step into TV, long life Conductive slip ring, High-quality belts, Stable operation, high reliability.
> Stable running, none dithering under any speed.
> Cover use high intension Aluminum material, with defend impact, shielding and heat dissipation function, defend levels reach to IP66.
> Internal setting data not lose when electronic cut.
> Triple lightning protection technology, effectively raising the speed dome mine and anti-jamming capability.

Technical program about Sony EFFIO:
EFFIO (Enhanced Features and Fine Image Processor. It has high resolution, high SNR and excellent Color reproduction). It was came into market by Sony. It had four versions: Effio, Effio-E, Effio-P, Effio-S.

Features of EFFIO-E:
1/3 "Sony EX-VIEW HAD II CCD with high-quality and high- sensitivity. Up to 650 tvl of horizontal resolution, high-definition images, excellent low light performance.
1. Range of AWB. Is 1.8 ~ 10K, it can monitor environment with a variety of shine.
2. Digital WDR...Excellent color reproduction (ATR Auto Levels adaptation).
3.2D DNR...In the case of low light, obtained clean and delicate images.
4.8 language OSD menu, powerful, high brightness compensation, strong light inhibition.

Advantage:

The first company Research and Develop speed dome module and housing in China.
Best: Our speed dome module + our housing

4" Non-infrared mini intelligent high speed doom series (K series)
Madel No.	BQL/KeX39-10
Image Sensor	1/4" SONY CCD
Signal Model	PAL/NTSC
Horizontal Resolution	480TVL
Effective Pixel	PAL:500(H)X582(V) NTSC:510(H)X492(V)
Minimum Illumination	0.001Lux-0.05Lux, Color to B/W
Application Environment	Indoor/Outdoor
Installation way	histing mounted , wall mounted
Housing protection	IP66
S/N Radio	? 50dB ( enhanced )
Filter	single filter, IR sensor
Backlight Compensation	On/Off
White Balance	Auto
Electronic Shutter	PAL:1/50~1/10000 seconds, NTSC:1/60~1/12000 seconds
Lens	Megapixel / 3.8-38mm
Optical zoom	10X
Digital zoom	Optional 10X
Focus	Auto/manual , take high-performance DSP to realize complete digital and ultra-high speed focus function.
Preset	255
Pattern scan	4 groups , each can record 200 actions
Tour scan	4 groups ,every group have16 presets can join cruise,can setting the presets'residence time
Other Scan	4 groups, support horizontal scan, deuce area scan, scan random
Rotation Range	Horizontal 360° unlimited rotation , Vertical 180° , auto reversal
Rotation Speed	Horizontal & Vertical Min 0.01°/s, Max 300°/s
Camera protocols	supported SONY or Samsung
Communications	RS485, PELCO D, PELCO P
Baud Rate	2400/4800/9600/19200
Dome address	255
Camera menu	8 languages
OSD	Whole screen Chinese/English menu
Special function	AWB,MASK,DNR,Strong light inhibition,Mirror
Power Supply	DC12V/1.5A
Material	Aluminum shell
Work Environment	-20 degrees Celsius ~+50 degrees Celsius (select temperature control accessories), < 95%RH
