Infrared Curing Lamp Heating Painting Spraybooths

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:$8150.0 - $10600.0 / Set

Min. Order (Sets)	Unit Price
1.0	US $ 8150/ Set
6520.0	US $ 10600/ Set

Trade Terms: FOB, CFR, CIF, EXW

Payment Terms: L/C, T/T, Cash

Price Valid Time:From Apr 11, 2014 To Apr 18, 2014

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:YS-A3

Certification:CE

Airflow Direction:Downdraft Airflow Way

Heating Mode:Infrared Curing Lamps

Paint Mist Treatment:Dry-type

Condition:New

Ventilation:Downdraft Airflow Way

Air Intake:1X7.5kw Turbo Fan

Air Exhaust:Optional

Heating:10 Units High Energy Short Wave Infra-Red Lamps

Voltage:1X220V, 3X380V, Your Special Voltages Are Accepted

Optional Colour:White, Blue, Orange and Red

Main Product:Spray Booth, Prep Station, Infrared Curing System

Export Markets:Global

Additional Info.

Trademark:YOKISTAR

Packing:Bubble Film Packing for Sea Transportation in Bulk

Standard:20?GP can load 1 set, 40?GP 2 sets, 40`HQ 3 sets.

Origin:Guangdong, China

HS Code:84198990

Production Capacity:120units/Month

Product Description

Industrial Painting Booth Is a Cheap Spray Booths by Top Spray Booth Supplier
Model: YS-A3
Inside dimention: 6900*3900*2650mm L*W*H
Any Size Requirements Can Be Met.
With infrared curing lamp for heating

A. During painting, spray booth can offer a sealed environment with cleanness, safety and excellent lighting for the painting operation of all kind of components and different products.
B. During baking, drying time, temperature and humidity in spray booth can be set according to different paint materials to achieve a perfect high-quality spraying and baking for your cars.
C. Spray booth makes spraying and baking operation with no limits of all kinds of whether, thus ensuring physical fitness of operators and absolute safety of equipments.

The purpose of YOKISTAR spray booth is achieving the fastest drying time, the lowest operation costs and as little environment impact as possible.
In order to promote the efficiency of the workshop and enlarge the profits for our customer, Yokistar spray booth has following advantages:

1. Ventilation
Yokistar spray booth is designed with several ventilation systems to guarantee the best painting conditions. All the filter system and air exhaust underneath create a vertical efficient air flow that is distributed evenly inside the booth and allows overspray to be removed immediately at all space around the vehicle.

2. Air recirculation on bake cycle
100% of the air handled by the fan is put into YOKISTAR spray booth during the bake cycle and only 15%-20% is expelled outside from there, while the balance 85%-80% is recovered and filled up with fresh air by means of the changeover damper.

Even temperature distribution in all points around the vehicle being painted rapid reaching of bake temperature and consequent reduction of bake times high energy savings due to recovery of most of the heat produced for the bake cycle

3. Lighting
The illumination is provided by four-tube, 36-watt light fixtures in the angled ceiling panels and side walls. They are sealed with 0.5mm clear and tempered safety glass. Correct lighting in YOKISTAR spray booth should be required for the good conditions for the painter.

4. Filters
The filtering is composed of high-efficiency heat, dust, paint resistant micro filters. The large surface covered and their progressive density guarantee high dust retention capacity and low resistance to the air passage. The long life of these filters considerably reduces frequency of replacement, contributing to reductions in running costs.

Warranty
The goods are guaranteed for 12 months from the date of receipt, but the filters and lamps are not guaranteed. It cannot be applied for damages caused by negligence of operations or mishandling of the machine.

YOKISTAR Products
High quality and advanced technology are applied in YOKISTAR product ranges, involving automotive spray booth, bus and truck spray booth, prep station, mixing room, bench spray booth, open face spray booth and infrared curing lamp.

Specification for YS-A3
Inside dimension	6900в3900в2650 mm(LвWвH)
Outside dimension	7000в5200в3400mm(LвWвH).
Wall panels	Thickness:50mm, width:1150mm, tongue and groove structure, with polystyrene (EPS) insulation inside, colour: white.
Doors	Folding door, 3 folds, 3000в2600 mm(WвH), made by bending steel without cover frame, colour: blue.
Doors	Escape door :1 unit , 650в1800mm(WвH), colour: white.
Basement	Galvanized steel assemble, 300mm high. quadrate steel frame, 2 rows of grilles made by flat bar and twisted steel, then painted, and 3 rows of indented plates, surface is painted. 2 ramps, external setting,520в2000mm.
Intake air system	1x7.5KW turbo fan for intake air, direct drive, air capacity: 25000m3/h.
Intake air system
Exhaust air system	Optional
Heating system	With 10 units high energy short wave infra-red lamps for heating. 3pcs/ unit, each lamp 1LW, total power of infra-red lamp:30KW
Heating system
Filtering system	Intake air pre-filter, ceiling filter, fibreglass filter
Lighting system	Ceiling Lights: 8Unitsв4Pcs=32Pcsв36W, with electronic ballast.
Control system	Spraying, baking, time setting, lighting switch, failure indicator, thermostat, power supply switch.emergency stop
Total power	39KW
