HOWO A7 6X4 420HP Heavy Duty Tractor Truck

Live chat with Seller

If you want to live chat with Seller ,Please - LOGIN to View Links.

HOWO A7 6X4 420HP Heavy Duty Tractor Truck

More Views

HOWO A7 6X4 420HP Heavy Duty Tractor Truck

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (unit)	Unit Price
1.0	US $ 40000.0-45000.0/ Piece

Price:$40000.0 - $45000.0 / Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T, CAD

Price Valid Time:From Aug 11, 2015 To Oct 10, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:ZZ4257V3247N1B

Transmission Type:Manual

Power:Diesel

Load Capacity:41-50t

Emission Standard:Euro 2

Drive Wheel:6×4

Seats:?5

Horsepower:351-450hp

Engine Capacity:?8L

Tire Type:Inner Tube

Tire Certification:ECE, ISO

Tire Design:Radial

Condition:New

Engine Output:420HP

Truck Type:Tractor Truck

Driving Type:6X4

Export Markets:South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia

Additional Info.

Trademark:SINOTRUK A7

Packing:Nude

Standard:70T

Origin:China

HS Code:870120000

Production Capacity:100, 000 Units/Year.

Product Description

A new generation highway Towing Truck with low dead load; the elegant shaping and the luxury decorations give you the comfort driving experiences, making it a perfect choice for the highway long-range standard-load transportations and medium-short range transportation tasks, especially available as a container carrier.
HOWO A7 6X4 420HP Heavy Duty Tractor Truck [HOWO-A7] ZZ4257V3247N1B
Technical Specification

Mass Parameter	Curb Weight(kg)		8800
	Loading Capacity(kg)		50000
	GVW(kg)		70000
Dimensions	Overall Dimensions	Length(mm)	6985
		Width(mm)	2496
		Height(mm)	3850
	Wheel Base(mm)		3200+1400
	Minimum Ground Clearance(mm)		280
Performance Parameters	Maximum Speed(km/h)		101
	Economic Speed(km/h)		70
	Maximum Gradability(%)		25
	Minimum Turning Diameter(m)		15

Vehicle Configuration

Engine	Model	D12.42
	Net Power(kw)/Rotating Speed(r/min)	309/2000
	Maximum Torque(Nm)/Rotating Speed(r/min)	1820/1100-1500
Gearbox		HW19712
Clutch(mm)		430
Rear Axle Type		ST16
Rear Axle Gear Ratio		4.42
Oil Tank(L)		400
Chassis Cross Section(mm)		270
Suspension (Frontal & Rear Springs)		9/12
Tires		12.00R20, 12.00R22.5, 295/80R22.5,315/80R22.5
