Hot Sale off Grid Home Solar Mono Panels Ksm30W

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 0.45/

Price:US $0.45 / watt

Trade Terms: FOB, CFR, CIF, EXW

Payment Terms: L/C, T/T, D/P, Paypal, Western Union

Price Valid Time:From Jun 11, 2015 To Sep 08, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:30w 4*9

Material:Monocrystalline Silicon

Leading Time:Within 7days

Package:Standard Export Carton

Export Markets:Global

Additional Info.

Trademark:KINGSUN

Standard:CE

Origin:Nanjing, Jiangsu

HS Code:8541402000

Production Capacity:8m Watts /Month

Product Description

Features:
High-efficiency solar cell ensures high performance of solar module and creates more power in peak hours
Anti-reflecting coating and high-transmission rate glass increases the power output and mechanical strength of solar module
Aluminum frame
Torsion and corrosion-resistant anodized frame ensures dependable performance, even though harsh weather conditions
Lightweight and pre-drilled mounting holes for easy installation
Water-resistant junction box
Designed specially to meet customers' demands for residential, commercial and industrial use.

Power Production Tolerance:± 3 %	Maximum System Voltage: DC 1000 V
Temperature coefficients of Isc (%) :+0.1/ ºC	Temperature coefficients of Voc (%) : -0.38/ ºC
Temperature coefficients of Pm (%) :-0.47/ ºC	Temperature coefficients of Im (%) : +0.1/ ºC
Temperature coefficients of Vm (%) :0.38/ ºC	Temperature Range : -40ºC~+80ºC
Max. Wind Load / Max Snow Load:2400 Pa /5400 Pa	Standard Test Conditions :Irradiance 1000W/,Moduletemperature25ºC,AM=1.5
Warranty :10 years 90% power output, 20 years 80% of power,25 years lifetime

Mono Solar Panel Model	Power (Wp)	Solar Cell Array	Size: MM ( L x W x H )	Vmp (V)	Imp (A)	Voc (V)	Isc (A)
KSM5	5w	36PCS(2x18)	310x190x28mm	17.56	0.286	21.52	0.31
KSM10	10W	36PCS(2x18)	380x290x28mm	17.56	0.6	21.52	0.66
KSM15	15W	36PCS(2x18)	510x290x28mm	17.56	0.86	21.56	0.93
KSM20	20W	36PCS(2x18)	500x350x28mm	17.56	1.14	21.56	1.23
KSM25	25W	36PCS(4X9)	610x350x28mm	17.62	1.42	21.10	1.63
KSM30	30W	36PCS(4X9)	520x510x28mm	17.56	1.71	21.56	1.84
KSM35	35W	36PCS(4X9)	590x510x28mm	17.56	2.00	21.56	2.20
KSM40	40W	36PCS(4X9)	660x510x28mm	17.56	2.28	21.56	1.84
KSM45	45W	36PCS(4X9)	730x510x35mm	17.56	2.57	21.42	2.88
KSM50	50W	36PCS(4X9)	800x510x35mm	17.74	2.84	21.56	3.04
KSM55	55W	36PCS(4X9)	870x510x35mm	18.20	3.04	21.85	3.24
KSM60	60W	36PCS(4X9)	720x680x35mm	17.56	3.43	21.52	3.68
KSM65	65W	36PCS(4X9)	770x680x35mm	17.56	3.71	21.42	4.15
KSM70	70W	36PCS(4X9)	820x680x35mm	17.20	4.10	21.60	4.22
KSM75	75W	36PCS(4X9)	870x680x35mm	17.56	4.28	21.45	4.78
KSM80	80W	36PCS(4X9)	930x680x35mm	17.74	4.51	21.56	4.98
KSM85	85W	36PCS(4X9)	980x680x35mm	18.10	4.70	21.63	5.10
KSM90	90W	36PCS(4X9)	1030x680x35mm	17.86	5.04	21.60	5.45
KSM95	95W	36PCS(4X9)	1050x680x35mm	18.22	5.21	21.85	5.71
KSM100	100W	36PCS(4X9)	1170x680x35mm	17.79	5.63	21.56	6.09
