Description

Details

Basic Info.

Model NO.:BZB-Australian Spray Booth

Certification:CE

Condition:New

Color:as Require

Voltage:as Require

Export Markets:Global

Additional Info.

Trademark:BZB

Packing:Polyfoam and Carton

Standard:CE and ISO 9001

Origin:Guangzhou, China

HS Code:84198990

Production Capacity:500per/Year

Product Description

Australian Standard Spray Booth: Our standard spray booth model BZB-8500 is a model that is specially designed for the Austrilian market and the European market, with nice design and nice materials used to ensure the long life span and the safety requirements of the spray booth.

Spray booth, BZB-8500, Australian Standard Spray Booth
External Size (mm)	7040x5500x3450
Internal Size (mm)	6900x4000x2650
Cabin System	1. Wallboard	EPS (epispastics polystyrene)Colorful Steel Skin Boards, 70mm Thick, Tongue & Groove Style, Compound Construction, Aluminum-alloy Frame, Anti-flame and Heat-Insulation


	Full Grid, Adjustable Height, Galvanized Steel Sheet Construction, Three Embossed Steel Ramps.

Air circulation system	Inhaling Ventilator		Model: YDW 4.5L	Exhaust Ventilator	Model: YDW 5.6M
			Blower capacity: 14000m 3 /h		Blower capacity: 21000m 3 /h
			Pressure: 800Pa		Pressure: 800Pa
			Rolling speed: 940rpm		Rolling speed: 900rpm
			Power: 4kw		Power: 7.5kw
			Quantity: 2 sets		Quantity: 1set
	Air Volume: 28000m 3 /h; Air Speed: 0.4m/s




Air Purification System	Dual Filtering Structure, The Primay Filter Can Capture Granules Larger than 10 ? m. Ceiling Filter Capture Granules Bigger than 5? m. The Whole Purification System Has Capacity of Large Volume of Dust. Its Filtering Rate Reaches 98%. Air Pressure Balance Gauge, TSP? 1.4mg/m 3




Heating System	1. Burner	Italy Riello Brand, RG5S Diesel Burner, 260000Kcal/h, 20N Damp Motor


	2. Heat Energy Converters	Stainless Steel, Argon Arc Welding, The Heat Exchange Rate 85%


	Max Temp: 80 centi degree, Heating Time: 4-5min(20-60centi degree), Fuel Consumption: 4-5kg/vehicle

Light System	Ceiling Light: 32 pcs 36w Philips Lamp; Bottom Light: 16 pcs 36w Philips Lamp, 1000 Lux


Electric controlling system	Micro Computer Programe Controlling, Spray & Baking Switch, Light Switch, Emergency Stop, Breakdown Alarm

Environmental Conversation System	Multi-Layer Fiberglasss Filter
