High Quality 20cbm LPG Truck with 270HP Engine

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 30000.0-50000.0/ Piece

Price:$30000.0 - $50000.0 / Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T

Price Valid Time:From Apr 29, 2015 To Jul 29, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:SLG20

Constituent:Industrial Mixture

Grade Standard:Industrial Grade

Chemical Property:Inflammable Gas

Overall Dimensions(Mm):11995*2500*3690

Power:270HP

Displacement(Ml):9726

Engine Type:6 Cylinder in Line,Water Cooling, Charged Inter-Co

Filling Medium:LPG(Propane)

Tank Volume(L):20,000

Density of Medium:420(50°)(Kg/M3)

Designed Pressure:1.77MPa

Max Worked Pressure:1.94MPa

Export Markets:South America, Southeast Asia, Africa, Mid East, Eastern Asia

Additional Info.

Trademark:SLCM

Packing:Container or Nude

Standard:CCC, BV

Origin:Shandong

Production Capacity:500 Units Per Month

Product Description

Introduction

LPG Transportation Truck is mainly used to transport LPG,include propane, isobutane, etc liquefied petroleum gas. We can offer different capacity of LPG truck and trailer and storage tank.Include 5.5m3 to 35.m3 LPG truck ,30m3 to 58.5m3 LPG semi trailer, and 10m3 to 100m3 storage tank.
Our factory is appointed by the Ministry of Industry and Information Technology of China, is a big manufacturer producing all kinds of special trucks.

Spec

vehicle	Vehicle Type	Foton chassis	Tank	Medium	Propene
	Vehicle Name	Tianlong LPG truck		filling ratio	420kg/m3
	Overall dimension	11995×2500×3690		designed temperature	50°C
	Actual Capacity	34.5M3		designed pressure	1.77Mpa
	Curb weight	16315		Max worked pressure	1.94Mpa
	Chassis model	ZZ1317M4667N1		corrosion allowance	1.0mm
	Engine model	D10.27-31 (Europe III)		Volumn	20M3
	Engine exhaust/horsepower	9726/270(ML/HP)		Loading capacity	14.49T
	Front/rear overhang	1540/2530		tank dimension	8757×2374mm
	departure angle	11/10		tank material	16MnIII
	axles load	6500/7000/17500		Tank thickness
	wheel base	1950+4250+1300		heat treatment	Whole body
	Number of tires	12		Shot blasting	Whold body
	tire specification	11.00-20,12.00-20,11.00R20,12.00R20	Special function	safety valve , ,Liquid Indicator ,pressure indicator,termperature indicator,Emergeny Cut-off Valves ,fire bottle ,antistatic earthing tape ,protective guard ,tire security board ,
	Front track base	2022/2022
	rear track base	1830/1830
