Hex Socket Set Screws Flat Point Oval Point Half Dog Point Cup Point Cone Point

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:$0.01 - $0.05 / Piece

Min. Order (Pieces)	Unit Price
2000.0	US $ 0.05/ Piece
100000.0	US $ 0.01/ Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T

Price Valid Time:From Jan 20, 2015 To Apr 20, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:LKDQ

Material:Stainless Steel, Alloy Steel, Steel

Type:Headless

Connection:Common Bolt

Head Style:Headless

Standard:DIN, ANSI, GB, JIS, BSW

Application:Machinery

Finish:Passivated, Zinc

Sample:Free

Export Markets:Global

Additional Info.

Trademark:LK

Packing:Bulk Packing, Small Box

Standard:DIN, ANSI, ISO and Non-Standard

Origin:China

HS Code:7318

Production Capacity:500 Ton/Month

Product Description

Hex Socket Set Screws Flat Point Oval Point Half Dog Point Cup Point Cone Point
1> Decription: Hex Socket Set Screws Flat Point Oval Point Half Dog Point Cup Point Cone Point
2> Material: Stainless Steel, Alloy Steel, Steel
3> Surface: Passivated, Zinc, Plain, Black Phosphated
4> Size: #10-3/4, M2-M20
5> Mechanical Properties: Class 8.8, 10.9, 12.9, A2, A4
7> Packing: Bulk packing and box packing

We professionally produce holding screw such as hollow-head setscrew, wabbler, screw nail etc. The product standard contains DIN, GB, ANSI, ISO, JIS. Imported equipments, materials and matrixes are used in the company. The materials involve 304, 302, 316, Scm435, 35 ACRs and domestic high-quality copper material. Function grade: Stainless steel, 45 H, 33 H. Specification M2- M20, the length has no limit. We also make high quality product which is not standard.

Please feel free to contact us if you are interesting our products. We are strongly believe will guarantee you the best quality and service for our more than 30 years professional experience.

Technical Delivery Conditions
Material		Steel	Stainless steel		Non-ferrous metal
General requirements		As specified in DIN 267 part 1
Thread	Tolerance	5g / 6g
	Standard	DIN13 Part 12 & 15
Mechanical properties	Property class	45H	?M20	A2-70	Subject to agreement
				A4-70
			>M20	A2-50
				A4-50
	Standard	ISO 898 Part 1	ISO 3605, DIN267 Part 11		DIN267 Part 18
Limit deviations geometrical tolerance	Product grade	A

	Standard	ISO 4759 Part 1
Surface finish		Black Oxide	Bright		Bright
		DIN267 Part 2 shall apply with regard to surface roughness
		DIN267 Part 9 shall apply with regard to electropiating
Acceptance inspection		DIN267 Part 5 shall apply with regard to acceptance inspection
