Hex Socket Head Cap Screw Allen Bolt Allen Screw

Live chat with Seller

If you want to live chat with Seller ,Please - LOGIN to View Links.

Hex Socket Head Cap Screw Allen Bolt Allen Screw

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:$0.05 - $0.08 / Piece

Min. Order (Pieces)	Unit Price
20000.0	US $ 0.08/ Piece
100000.0	US $ 0.05/ Piece

Trade Terms: FOB, CFR, CIF, EXW

Payment Terms: L/C, T/T, Western Union

Price Valid Time:From Jun 09, 2015 To Dec 31, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description
Additional Information
Reviews

Description

Details

Basic Info.

Model NO.:LKUW

Material:Stainless Steel, Alloy Steel, Steel

Type:Hex Socket

Groove:Hexagon

Connection:Common Bolt

Head Style:Hex Socket

Standard:DIN, GB, ANSI, BSW, JIS

Grade:Class 8.8, 10.9, 12.9; Grade 5, 8; A2, A4

Sample:Free (If in Store)

Market:Global

Additional Info.

Trademark:LK

Packing:Bulk Packing, Small Box Packing

Standard:DIN, ANSI, ISO and Non-Standard

Origin:China

HS Code:7318

Production Capacity:5000 Tons/Month

Product Description

Hex Socket Head Cap Screw Allen Bolt Allen Screw
1. Description: Hex Socket Head Cap Screw Allen Bolt Allen Screw
2. Material: Stainless Steel, Alloy Steel, Steel
3. Surface: Plain, ZincPlating, Passivation
4. Size: M3~M20, 3/16"~3/4"
5. Property: Class 8.8, 10.9, 12.9; Grade 5, 8; A2, A4

We produce and export the Hex. Socket head Cap screw per ASME B18.3 DIN912...And some special ones per the drawing of the client.

Please feel free to contact us and send us your inquiry once you are interesting it.

Technical Delivery Conditions
Material		Steel	Stainless steel		Non-ferrous metal
General requirements		As specified in DIN 267 part 1
Thread	Tolerance	Class 12.9: 5g / 6g; Others: 6g
	Standard	ISO 261, ISO965; DIN13 Part 12 & 15
Mechanical properties	Property class	?M39: 8.8, 10.9, 12.9 >M39: Subject to agreement	?M20	A2-70	Subject to agreement
				A4-70
			>M20 & ?M39	A2-50
				A4-50
			?M39	C3
			>M39	To agreement
	Standard	ISO 898 Part 1	ISO 3605, DIN267 Part 11		DIN267 Part 18
Limit deviations geometrical tolerance	Product grade	A

	Standard	ISO 4759 Part 1
Surface finish		Black Oxide	Bright		Bright
		DIN267 Part 2 shall apply with regard to surface roughness
		DIN267 Part 19 shall apply with regard to permissible surface discontinuities
		DIN267 Part 9 shall apply with regard to electropiating
		If different electroplating or other surface protection is desired, this shall be agreed upon at the time of ordering
Acceptance inspection		DIN267 Part 5 shall apply with regard to acceptance inspection
