Product Description:
1. The Cortex A8 1.2GHZ dual-core processor with strong functions, 1GB DDR3 interior storage, built-in 8GBspace for you to store file;
2. The Android4.2/4.4 operation system, which more convenient, more stabilized;
3. Support various resolution, including 800*480;
4. Support TMC(Traffic Message Channel), Real-time traffic information;
5. Support add e-dog full frequency moving speed radar;
6. With strong display adaptability, can directly adjust display size, position, height, contrast, color and saturation and other parameters on screen to match with different screens of different manufacturers and different display effect of different navigation map.
7. Support touch screen operation, share a touch screen with car DVD through a serial port according software agreement;
8. Can upgrade software OS through SD(TF)card;
9. Support hardware recover factory setting;
10. Support wireless WiFi network connection and 3G internet function to meet your different needs in different environment;
11. Add TF/SD card, maximum can support 32G;
12. USB 2.0 OTG, HOST interface, support the product connect to computer, and storage dev2. Support add U flash disk, maximum can support 32G, support add hard disk;
13. Support various of video format: AVI(H. 264, DIVX, DIVX, XVID, rm, rmvb, MKV(H. 264, DIVX, DIVX, XVID), WMV, MOV, MP4(H. 264, MPEG, DIVX, XVID), MPEG, MPG, FLV(H. 263, H. 264);
14. Support comprehensive audio format: WAVE, AIFF, AU, MP3, MIDI, WMA, RealAudio, VQF, OggVorbis, AAC, APE;
Support AVIN
Product specification:
Product parameter
Main Frequency: 1.2G~1.5G Hz
Main chip model: Allwinner A20
Memory: 1GB DDRIII
Storage Space: 8GB NAND Flash
Navigation storage software: SD card/TF card
Operation system: Android 4.2/4.4
Multimedia parameter and features
Support audio format: WAVE, AIFF, AU, MP3, MIDI, WMA, RealAudio, VQF, OggVorbis, AAC, APE etc.
Support video format: AVI(H. 264, DIVX, DIVX, XVID, rm, rmvb, MKV(H. 264, DIVX, DIVX, XVID), WMV, MOV, MP4(H. 264, MPEG, DIVX, XVID), MPEG, MPG, FLV(H. 263, H. 264)etc.
Video decoding function: Support1080PHD video display
Picture viewer
Support picture format: BMP/JPG/GIF/PNG etc.
Text viewer
Support text format: TXT
Internet
Support network type: EVDO/W-CDMA/WiFi
Support network speed: 7.2M/S
GPS hardware parameter
ChipsetSIRF III or U-BLOX 6
Frequency1.575GHZ
C/A CODE1.023 MHZ chip rate
The number of channel20channels
Tracking sensitivity-159dBm
Positioning accuracy10m, 2D RMS
5m, 2D RMS, WAAS enable
Rate update rate0.1m/s
Data 1HZ
Reacquisition timeAverage 0.1s(OPEN SKY)
Hot start timeAverage 3s(OPEN SKY)
Warm start timeAverage 38s(OPEN SKY)
Cold start timeAverage 45s(OPEN SKY)
Maximum positioning height18, 000m
Maximum rate515m/s
Acceleration< 4g
Interface of external antenna SMA
Voltage of external antenna 3.3V� 5%
External antenna gain27dB
Current of external antenna15mA
USB parameter and function
USB interface typeUSB 2.0(High Speed)Device
USB functionSupport PC connection and U fash Disk
