GPS Navigation for Jvc001 (LLT-JV3301)

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:

Min. order:1 Piece

Trade Terms:FOB

Payment Terms:L/C, T/T

Trademark:Lsailt

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:LLT-JV3301

Type:GPS Navigator

Use:Automotive

Operating Principle:Code Related Type

Port Number:Sequencing Channel

Model:Geodesic Type

Screen Size:7"

Carrier Frequency:Single Frequency

Chip:MStar

Brand:Lsailt

Export Markets:Global

Additional Info.

Trademark:Lsailt

Packing:Cartons

Standard:SGS CE FCC

Origin:Shen Zhen, Guang Dong

Production Capacity:50, 000PCS/Year

Product Description

Product Description

HD/Mimic Navigation Box,,Navigation System,,GPS Navigator,GPS Box,,Car Black Box for Alpine, JVC, Kenwood, Philips, Pioneer, Sony, Clarion with Clarion-VX-709A etc;
Philips-CED-1700/6900DVDetc;
Pioneer-AVH-P6300BT/P8400BH/X8500BHS/X7500BT/X6500DVD/X4500BT/X2500BT/X1500DVDetc;
JVC-KW-V10/V60/KW-AVX646/735/736/835/836/746/846/648/848;
Alpine-IVA-W200E/201E/202E/502E/520C/530E/X8etc:
Sony-XAV-701BT/XAV-622
Installation advantages

1)   Nondestructive installation design, which does not damage to the wires of original car; special interface cable, plug-up installation without wire cut;

2)   Choose installation functions freely(Bluetooth optional);
3)   Technology is reliable, take the original agreement;
4)   After the upgrade, it still retains all the functions of the original host, even if navigation goes wrong, does not affect the function of the use of the original car;5)   After-sales service is convenient, replace the adapter module directly, compare with special machine, it's simple, less risk, safety and reliable
6)   Choose beautiful interface by yourself;
7)   Achieve handwritten navigation, and control the navigation by touching it. Compare with the original navigation module, it's more convenient and flexible.

Product accessories

Mainframe

1(standard configuration)

Dedicated wire

1(standard configuration)

Antenna

1(standard configuration)

Specification

1(standard configuration)

certification

1(standard configuration)

Warranty card

1(standard configuration)

Microphone

1(optional configuration)

Horn

1(optional configuration)

Map card

1(optional configuration)

Mute dedicated line

1(optional configuration)

Product parameters

Frequency:

800MHZ/1GHZ

Main chip model:

MSB2531 /735

Memory:

256MB

Storage space:

128MB(can expand to 8GB)

Navigation software storage:

SD card

Operating system:

WINCE6.0 CORE

Supported audio and video formats:

MP3/PCM/WMA/ Mp4/mpeg/mpg/asf/wmv/mov etc.

Support video type:

Mp4/mpeg/mpg/asf/wmv/mov etc.

Video output format:

Composite Video(CVBS,Y/C,YPbPr)/ Analog RGB

Video output voltage:

1.0Vpp/75?

Resolution:

800X480

Sound output:

Dual channel CD stereo sound

Operating temperature:

~40 to +85

Storage temperature:

~40 to +100

Operating voltage:

DC 9-16V

Tracking sensitivity:

~161dBm

Positioning accuracy:

10m, 2D RMS,5m, 2D RMS, WAAS enable

GPS Antenna type:

External active ceramic antenna

For models:KW-V10/V60etc. all machine with NAVI interface . ( 800X480 )
