Good Quality 50000 Litres Oil Tanker Semitrailer

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 28500/ Piece

Price:US $28500.0 / Piece

Trade Terms: FOB, CFR, CIF, EXW

Payment Terms: L/C, T/T, Paypal, Money Gram, Western Union

Price Valid Time:From Jan 06, 2015 To Apr 06, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:FTW9560GYY

Type:Towing Pin

Towing Pin Material:Carbon Steel

Impeller Type:Closed Type

Hook Type:Single

Universal Joint Type:Flexible Universal Joint

Brake Pad Material:Ceramic

Towing Pin Type:Mushroom Type

Towing Pin Diameter:50mm

Differential Gear Type:Gear Type

Independent Suspension Type:Trailing Arm Type

Size:as Your Request

Colour:Custom Painting

Use:Oil Storage

Export Markets:North America, South America, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia

Additional Info.

Trademark:Jupiter

Packing:Nude

Standard:ISO

Origin:Xiamen, China(Mainland)

HS Code:87163990

Production Capacity:5000 Units/Year

Product Description

Type tanker semi trailer
Product Name Fuel/Oil tanker semi trailer
Shipping Terms Shipping by bulk cargo because its huge body.
Delivery time Production Term 15 workdays for one set oil tank semi trailer
Weight
Tare Weight From 11550kg to 12800kg
Tanker capacity From 30m3 to 55m3 for your choose
Loading Capacity 30-60ton
Axle Weight Load 13/16/20T
Specification
Axle No. / specs. 2 or 3 FUWA or BPW brand
Tire 11.00R22.5/12.00R22.5 Vacunnm tire /Triangle or Double Cone brand
King Pin JOST 50# or 90# traction pin
Outside dimensions (L*W*H) 11000× 2490× 3950mm, 12500× 2490/2500× 3950/3800mm,
13000× 2490/2500× 3950/3900mm
Support legs 28Tons (Tongyada Brand)/Jost D200T
Rear ladder With ( as in the picture)
Rim 8.25× 22.5/9.00*22.5 Vacunnm tire Zhengxing Brand
Wheelbase 8050/7650+1300mm, 5060/6660/6960/6580+1310+1310mm
Steel Spring 10 pieces per axles
Compartment Three
Manhole 2/3/4 pieces(Diameter is 500mm)
Discharge mouth diameter is 280mm
Number of Tire can be choose freely
Fire Extingguisher Two pieces
Spare Tire Carriers 2pieces
Tool box 2PCS
Frame:
The material of
Tanker body The tanker body made of 5mm steel plate,
The forside head and back side head made of 6mm steel plate, the shape can be column or TV square shape.
Brake:
Brake Chamber Four double and two single chambers( TKL brand )
ABS system Without ( Can be choose freely)
Emergency Valve WABCO
Electriacl:
Voltage 24V
Receptacle 7ways (7wire harness)
Miscellaneous
Painting According to the requirement of the buyer
Marking According to the requirement of the buyer
Side Guard According to the requirement of the buyer
Tools box One pieces or According to the buyer

Overall Parameters
Cabin	T360 High-roof,Double Sleepers, Electric Hydraulic reversing
Engine	YC6M320-30
Gearbox	RT11509,Shanchi 9 Gears,High Speed
Front Axle	153 Double Front Axles
Rear Axle	457 Double Rear Axles
Chassis Frame	300 Double-deck
Front Leaf-spring	153 Thickened,9 Sheets,16mm
Rear Leaf-spring	2913Z02-010-B,10 Sheets,20mm
Tire	11.00R20,Steel Wire Tire
Wheel Rim	8.0-20,14cm
Air Compressor	Wuhu 9.0
Tank	42CBM,Three Chambers And Two Covers
Features:
1. Installed brand new air intake and powder discharge system,leading industry level in
discharging time and powder residual quantity.
2. Large tank capacity within 35-42 CBM, designed for medium and long-diatance transport.
The Specification Is Only For Reference. Custom made available.
