for Sale 4X2 Road Sweeping Truck with 5000L Garbage Tank

More Views

More than 10 available

Availability: In stock

Price:

Min. order:1 Piece

Trade Terms:FOB

Payment Terms:L/C, T/T

Trademark:CLW

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Login or Signup to View Links.

Description

Type:Sweep and Suck Type

Transmission Type:Manual

Emission Standard:Euro 3

Fuel:Diesel

Engine Type:2 Stroke

Cleaning Process:Cold Water Cleaning

Condition:New

Warranty:1 Year

Dimension:7000X2480X3000

Export Markets:Global

Trademark:CLW

Packing:Without Packing

Origin:Hubei, China

Production Capacity:500sets/Month

For Sale 4x2 Road Sweeping Truck With 5000L Garbage Tank

1.Conficuración básica y parámetro pricipal tecnología:

Main Technical Parameter
Product Name	Road Sweeper Truck	Overall Dimension(mm)	7000×2480×3000
Gross Weight(Kg)	11495	Curb Weight(Kg)	6800
Wheelbase(mm)	3950	Cab Allowed Persons	3
Axle No.	2	App./ Dep. Angle(º)	33/20
Axle Load(Kg)	4500/6995	Max Speed(Km/h)	90
Chassis Technical Parameter
Chassis Name	Truck Chassis	Chassis Brand	DONGFENG
Overall Dimension(mm)	7120×2462×2710	Tyre No.	6
App./ Dep. Angle(º)	33/22	Tyre Specification	9.00-20
Spring leaf No.	8/11+8	Front Track(mm)	1900
Drive Type	4x2	Rear Track(mm)	1800
Cab	Flattop with single row	Clutch	Single-dry diaphragm spring
Transmission	Recirculating ball transmission	Brake	Air Brake
Steering Wheel	Left Hand Drive	Gear box	6 speed forward with 1 reverse
Engine
Engine Model	B170-33	Engine Brand	Cummins
Displacement(ml)	5900	Power	170hp/125kw
Fuel Type	Diesel	Emission Standard	Euro III
Superstructure Technical Parameters
Garbage Tank Volume	5000L	Water Tank Volume	3000L
Brushes No.	4pcs	Auxiliary Engine	Cummins Brand,140hp
Remarks: Monitor device is optional
