First Automobile Works of China Faw 25 Tons Dumper

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 38000.0-49000.0/ Piece

Price:$38000.0 - $49000.0 / Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T

Price Valid Time:From Sep 28, 2014 To Dec 31, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:CA3256

Transmission Type:Manual

Power:Diesel

Load Capacity:21-30t

Emission Standard:Euro 2

Drive Wheel:6×4

Engine Capacity:?8L

Seats:?5

Horsepower:251-350hp

Tire Type:Inner Tube

Tire Certification:ISO

Tire Design:Radial

Dumping Type:Front Lifting Style

Condition:New

Truck Type:Dump Truck

Type:Dumper

Export Markets:South America, Southeast Asia, Africa, Mid East, Eastern Asia

Additional Info.

Trademark:FAW

Packing:Nude Packing

Standard:CCC

Origin:China

HS Code:87042300

Production Capacity:300 PCS/ Month

Product Description

First Automobile Works of China FAW 25 Tons Dumper

Overall dimensions Length 10488mm
Width 2500mm
Height 3185, 3480mm
Axle base (full load) 3760+1350.
Front overhang(loaded) 1438
Rear overhang(loaded) 1880

Wheel base Front wheel 2020
Rear wheel 1840

Ground clearance(loaded) Under front axle 285
Under rear axle 290
Passing angle(loaded) Approach angle 24
Departure angle 39

Mass
Parameter Curb weight (kg) 15725
Gross truck weight 31000
Payload weight(kg) 15080.

ENGINE: WP10.336N, WP10.340E32
TRANSMISSION: CA10T, FULLER 9JS135
REAR AXLE: LB300
TIRE: 12.00R20
Cargo box dimension: 5600X2300X1500. Mm

TRUCK SPECS	Overall d imension:		8000x2496x3450mm(26.25x8.19x11.32ft)/ 8545X2496X3170mm(28.04x8.19x10.40ft)/ 8675x2496x3450mm(28.46x8.19x11.32ft)/ 8845x2496x3450mm(29.02x8.19x11.32ft)
	Cabin	Cabin size:	standard cabin(2 seats)/ long cabin(2 seats and 1 bed)/ high cabin(2 seats and 2 bed)
		Seats and sleeper Bed:	2 seats and 1 bed/
		Air conditioner:	standard
	Engine	Horsepower(hp):	290 320 340 380
		Tech:	steyr tech
		Engine Type:	6-cylinder in line, 4-stroke, water-cooled,turbocharged, intercooled
		Emission Standard:	EUR 2
		Fuel Type:	Diesel
		Engine Capacity(ml):	9726
	Gear Box/Transmission		9/12 speeds and 1/2 reverse speed
	Clutch		?430
	Axles	Front Axles:	9T
	Axles	Driving Axles:	2x16T
	Tyre:		12.00-20,10 Radial tires with one spare tire/ 12.00R20,10 Radial tires with one spare tire
	Max speed:		75/80/85km/h
	Tare weight(MT):		12MT
BODY SPECS	Body Dimensions (LengthXWidthXHeight):		5400X2300X1500mm(17.72x7.55x4.92ft)/ 5500x2300x1500mm(18.04x7.55x4.92ft)/ 5600x2300x1500mm(18.37x7.55x4.92ft)/ 5800x2300x1500mm(19.03x7.55x4.92ft)/ 6000X2300X1500mm(19.70x7.55x4.92ft)/ 6200X2300X1500mm(20.34x7.55x4.92ft)
	Material:		Q235
	Body steel (mm):		floor 8mm(0.32in),side 6mm(0.24in)
	Cpacibility(M3):		20CBM 22CBM 25CBM 30CBM
	Lift System:		hydraulic system with power assistance
	Wheel base:		3825+1350mm(12.55x4.43ft)
	Track Width(front/rear):		2041/1830mm(7.91x6ft)
	Overhang(front/rear):		1500/1870mm(7.55x6.14ft)
	Approach/Departure Angle:		19°/23°
