FAW 8X4 30000L Oil Dispenser Tank Truck

Live chat with Seller

If you want to live chat with Seller ,Please - LOGIN to View Links.

FAW 8X4 30000L Oil Dispenser Tank Truck

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 9000.0-72000.0/ Piece

Price:$9000.0 - $72000.0 / Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T, D/P

Price Valid Time:From Apr 30, 2015 To Jul 10, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:CA1311P1K2L6T4EA80

Transmission Type:Manual

Power:Diesel

Load Capacity:31-40t

Emission Standard:Euro 3

Tank Volume:?30000L

Drive Wheel:8�4

Seats:?5

Horsepower:251-350hp

Engine Capacity:6-8L

Storage:Oil

Tire Type:Solid Tire

Tire Certification:ECE, GCC, ISO, DOT

Tire Design:Radial

Condition:New

Tank Capacity:30000L

Steering Type:Left- Hand Drive( Right-Hand Drive Can Opt)

Transmission:8 Gear

Tire Specification:10.00r20

Tyre Number:12

.Engine Type:Ca6dl1-26e3f

Driving Type:8X4

Export Markets:Global

Additional Info.

Trademark:FAW

Packing:Bulk and Wax Covered

Standard:CE

Origin:China

HS Code:8705909090

Production Capacity:2000units Per Year

Product Description

FAW 8X4 30000L oil dispenser tank truck

The Oil Tank Truck is also called Mobile Fuel Truck,Fuel Storage Truck, oil loading truck, oil trucks, etc. It is mainly used for storage of oil and oil transporting.

1.Tank materials: Optional for carbon steel, stainless steel, aluminium alloy,rotational lining plastic, and FRP;

2.Functions: The tank can be made to be separated compartments to load different oil or chemical varieties .and can be designed as as pump-in and pump-out through measurement;

3.Pump: According to the use of tankers, can choose centrifugal pumps, gear pump, copper gear pump, stainless steel pump, it has big flow,fast speed of suction and some other characteristics.

4.Fuel tanker capacity:from 3000 liters to 35000 liters(for truck);35000 liters to 55000 liters(for trailer)

5.Chassis driving modes can optional 4*2,4*4,6*2,6*4,6*6,8*4.Chassis brand optional Isuzu Dongfeng Foton JAC JMC FAW CAMC IVECO Hino Shacman etc.

Please let Ms.Vanessa know if need.
Mobile: 0086-13707173860

Chassis Technical Specification
Product Name		FAW 8*4 Oil Tank Truck
Chassis Model		CA1311P1K2L6T4EA80
Fuel type		Diesel
Cabin		One and half row
Vehicle information(mm)	Overall dimensions (L�W�H)	1112025003250
	Wheel base	1860+4200+1350
	Front overhang	1375
	Rear overhang	2415
	Min. ground clearance	535
Weight data (kg)	G.V.W	31000
	Curb weight (chassis)	11805
	Max payload	25000
Whole vehicle main performance	Max. speed (km/h)	79
Whole vehicle main performance	Max. slope of climb (%)	30
Engine	Model	CA6DL1-26E3F
	Maximum power	195kw / 265hp
	Number of cylinders	6
	Displacement (ml)	7700
Axle	Front Load capacity(ton)	6.5
	Middle Load capacity (ton)	6.5
	Rear Load capacity (ton)	18
Suspension	Leaf spring	12/12/10+7
Suspension	Leaf spring	12/12/10+7
Steering Wheel	left/right hand drive	optional
Brake system	Service brake	Air braking
Electric device	Rated voltage	24V
Tyres & Quantity		10.00R20&12+1
Special Performance&Equipment
Tanker	Fact cuabge	30 cbm
	Meterial	Q235 Carbon Steel(According to your demand)


	Thickness	5mm
Special function description	1.Can load different oils , chemicals ,and food separately 2.Can be designed to pump in -out and downgrade flow measured by flow meter or not!


Optional equpment description	1. Can be equipped with refueling pump , flow meter, tanker aircraft, refueling reel 2. Can be separated into several small unattached tanks
