FAW 20-25 Tons Middle Dump Truck

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (SET)	Unit Price
1.0	US $ 38900.0-56200.0/

Price:$38900.0 - $56200.0 / SET

Trade Terms: FOB, CFR, EXW, CIF

Payment Terms: L/C, T/T

Price Valid Time:From Oct 30, 2014 To Jan 30, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:Dump Truck

Transmission Type:Manual

Power:Diesel

Load Capacity:21-30t

Emission Standard:Euro 3

Drive Wheel:6×4

Engine Capacity:?8L

Seats:?5

Horsepower:251-350hp

Tire Type:Tubeless

Tire Certification:ISO

Tire Design:Tubeless

Dumping Type:Front Lifting Style

Condition:New

Truck Type:Dump Truck

Type:Middle Dumper

Export Markets:South America, Southeast Asia, Africa, Mid East, Eastern Asia

Additional Info.

Trademark:FAW

Packing:in Nude

Standard:CCC

Origin:China

HS Code:87042300

Production Capacity:30 PCS/ Month

Product Description

FAW 20-25 Tons Middle Dump Truck

6*4 Dump Truck/tipper truck/dumper truck
Type Number CA3310P2K2L4T4EA80
Overall dimensions Length 10488
Width 2500
Height 3185, 3480
Axle base (full load) 1860+3960+1350.
Front overhang(loaded) 1438.
Rear overhang(loaded) 1880.

Wheel base Front wheel 2020.
Rear wheel 1840

Ground clearance(loaded) Under front axle 285
Under rear axle 290
Passing angle(loaded) Approach angle 24
Departure angle 39

Mass
Parameter Curb weight (kg) 15725
Gross truck weight 31000
Payload weight(kg) 15080

ENGINE: WP10.336N, WP10.340E32
TRANSMISSION: CA10T, FULLER 12JS160T
REAR AXLE: LB300
TIRE: 12.00R20
Cargo box dimension: 7600X2300X1500.
Color: Red.
