Durable Faw 60 Tons Mining Dump Truck

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Sets)	Unit Price
1.0	US $ 110000.0-139000.0/ Piece

Price:$110000.0 - $139000.0 / Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T

Price Valid Time:From Oct 08, 2014 To Jan 31, 2016

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:mining dump truck

Transmission Type:Manual

Power:Diesel

Load Capacity:61-70t

Emission Standard:Euro 2

Drive Wheel:6×4

Engine Capacity:?8L

Seats:?5

Horsepower:451-500hp

Tire Type:Inner Tube

Tire Certification:ISO

Tire Design:Radial

Dumping Type:Front Lifting Style

Condition:New

Fuel:Diesel

Certification:ISO9000

Engine Type:4 Stroke

Volume:>30000L

Type:Mining Dump Truck

Payload:60 T

Export Markets:South America, Southeast Asia, Africa, Mid East, Eastern Asia

Additional Info.

Trademark:faw

Packing:Nude Packing

Standard:ISO

Origin:China

HS Code:8704230090

Production Capacity:30PCS/Month

Product Description

Durable FAW 60 tons Mining Dump Truck

Heavy Mining Truck Specification
Truck Model: FAW 60T Heavy mining truck
Driver Cabin: Reversible type wide-body offset the cab
Engine/horsepower: CA6DN1-46E3, 460HP
Gearbox: FAST FULLER 12JSD260
Steering: ZJ120
Front/Rear Axle: PX19T Front axle/PX 35T Double Reduction Rear Axle
Chassis: Welding Dumper Chassis 450*130(16+14)
Cargo inner dimension(mm): 5950*3310*1750=35m³
Description: Bottom16mm, side10mm, front lift, Manganse Plate, HYVA 196 Hydro-cylinder, Square dump box
Other specification: 16.00-25-28 Tyre for mining
Front/Rear Overhang: Overall welded balanced suspension
Front/Rear Axle Leaf Spring100*20*13, 120*32*13
Brake system: WABCO
Others: Three-level sand filter, exhaust braking
Tare weight(kg): 30000
Max weight(kg)60000
Gross weight(kg): 90000
Overall Dimension(mm): 9100*3500*4100
Max speed(km/h): 51
Min. Ground Clearance(mm): 435
Min turning Radius(m): ? 10m
Max grade ability(%): 41%
Approach/Departure(° ): 33° /45°
Wheelbase(mm): 3750+1690
Wheel track (mm): Front 2793, back 2580
Max torque(Nm)/rotate speed(r/min): 2100/1150-1350
Fuel tank(L): 600L Steel tank

Heavy Mining Truck Specification
Truck Model:	FAW 60T Heavy mining truck
Driver Cabin:	Reversible type wide-body offset the cab
Engine/horsepower:	CA6DN1-46E3, 460hp
Gearbox:	FAST FULLER 12JSD260
Steering:	ZJ120
Front/Rear Axle:	PX19T Front axle/PX 35T Double Reduction Rear Axle
Chassis:	Welding Dumper Chassis 450*130(16+14)
Cargo inner dimension(mm):	595033101750=35m³
Description:	Bottom16mm,side10mm, front lift, Manganse Plate, HYVA 196 Hydro-cylinder, Square dump box
Other specification:	16.00-25-28 Tyre for mining
Front/Rear Overhang :	overall welded balanced suspension
Front/Rear Axle Leaf Spring	1002013,1203213
Brake system:	WABCO
others:	Three-level sand filter\exhaust braking
Tare weight(kg):	30000
Max weight(kg)	60000
Gross weight(kg):	90000
Overall Dimension(mm):	910035004100
Max speed(km/h):	51
Min. Ground Clearance(mm):	435
Min turning Radius(m):	?10m
Max grade ability(%):	41%
Approach/Departure(°):	33°/45°
Wheelbase(mm):	3750+1690
Wheel track (mm):	Front 2793,back 2580
Max torque(Nm)/rotate speed(r/min):	2100/1150-1350
Fuel tank(L):	600L Steel tank
