Ctac Best Selling Low Bed Semi Trailer

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 15000/ Piece

Price:US $15000.0 / Piece

Trade Terms: FOB, CIF

Payment Terms: L/C, T/T

Price Valid Time:From Oct 31, 2014 To Jan 31, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:CTY9500GJY

Loading Capacity:From 40ton to 100ton

Export Markets:Global

Product Description

HIGH AND LOW BOARD SEMI TRAILER

SEMI TRAILER INFORMATION:
1. Components: chassis, suspension, tyre and wheel, landing gear;
2. Payload: 20ton, 30ton,40ton, 60ton, 100ton;
3. Quality level: excellent quality for international market, made in China
4. Certificate: ISO9001; TS16949; COC; PVOC; CIQ; SONCAP; BV; C/O; FORM E;
5. Area suitable: Australia, Africa, Middle East, South Africa...
SEMI-TRAILER FUTURES:
1. Apply to transport longer larger parts, miscellaneous pieces of cargo, large components and equipment.
2. Innovative design, tailored to local transport environment analysis on the basis of full understanding of, learn from the advanced design concept, many innovative.

3. Advanced means of production technology and perfect testing equipment to protect the the product overall structure is reasonable, reliable performance.
4. Frame body Q345B high strength structure steel, automatic submerged arc welding throughout beams, and other cross-section main stringers structure for optimum carrying effect.
5. Well-known brand axles, suspension systems, high performance, and reliable to use, to ensure the good performance of the vehicle.
6. Full braking and electrical systems at home and abroad in accordance with ISO standard, optional ABS system, braking, lighting is absolutely safe and reliable.
7. Frame overall spray primer treatment, paint spraying fine surface quality of maritime anti-corrosion standards.
8. Products fully comply with relevant national standard GB1589, GB/T6420, at the same time to meet the individual needs of customers.
WELCOME YOU AND YOUR FRIENDS COME TO VISIT OUR COMPANY AT ANY TIME!

Tare Weight	About 8.5-13T
Dimension	13000mm3000mm-3500mm1650mm (Size can be choose freely)
Loading Capacity (T)	40T-100T
Axle	13 T/16T, FUWA /BPW /Huajing Brand
Rim	6.5-20/7.5-20/8.00-20/8.5-20 (Special for export market)
Tire	8.25R20/10.00R20/11.00R20/12.00R20
Suspension	Mechanical suspension (Germany Type or America Type) Or Air suspension (China brand or BPW brand ) (Special for export market)
Spring leaf	90(W)mm13(Thickness)mm10 Layer or 100mm12mm12 (Special for export market)
King pin	JOST brand 2.0 or 3.5inch bolts type or Welding type
Support leg	JOST brand D200T or China brand 28Tons (Double speed)
Main beam	Height: 450mm-520mm, upper plate is 14mm-25mm, middle plate is 8mm-12mm, down plate is 16mm-25mm ; Material is Q345B Steel .
Side beam	16mm -30mm channel steel ( Material is Q235steel ).
Bottom Platform	3-6mm thickness diamond steel plate
Ladder	Manual or Hydraulic type
Gooseneck	For choose
Brake chamber	WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); one piece of 45L air tanks
ABS	Optional
Twist Locks	Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type)
Valve	WABCO valve
Light	LED light (Special for export market)
Voltage	24V
Receptacle	7 ways (7 wire harness)
Tool box	One piece, 1m×0.5m×0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar)
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Shipping Terms:	By bulk cargo carrier, RORO or 40HQ container.
