China Brand XCMG 30ton Horizontal Directional Drilling Machine Xz280

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:$10000.0 - $100000.0 / Piece

Min. Order (Pieces)	Unit Price
1.0	US $ 100000/ Piece
4.0	US $ 10000/ Piece

Trade Terms: FOB, CFR, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA, EXW

Payment Terms: L/C, T/T, D/P, Paypal, Money Gram, Western Union

Price Valid Time:From Jul 29, 2015 To Dec 31, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:Xz280

Structure:Horizontal Drilling Machine

Layout:Horizontal

Controlling Mode:CNC

Automatic Grade:Automatic

Precision:High Precision

Certification:GS, SGS, CE, RoHS, ISO 9001

Condition:New

Engine:Shangchai

Engine Rated Power:140kw

Max.Pullback/Thrusting:280kn

Dimension (Lxwxh):7100×2260×2450mm

Overall Weight:12500kg

Export Markets:Global

Additional Info.

Trademark:XCMG

Packing:Nude Packing

Standard:CE, ISO9001

Origin:Jiangsu, China

HS Code:84306919

Production Capacity:100 Set/Sets / Month

Product Description

Product Description
China brand XCMG 30ton Horizontal Directional Drilling Machine Xz280

Technical Features of XZ280:
Dual speed power head: Drilling and pulling at low speed ensure smooth operation; The power head can slide at faster speed to reduce the auxiliary time and improve work efficiency during the assembly/disassembly of drilling stem with empty load.
Rubber track: The rubber track has minor influence on the road, lawn, and scenic spot.

Float clamp: The patented float clamp can effectively extend the service life of the drilling shaft.
Automatic assembly/disassembly: The drill stem can be mounted and dismounted automatically, which improves the work efficiency, reduces the work intensity and thus reduces the number of work staff.
Automatic anchoring: Through hydraulic pressure drive, the cylinder and low speed large torque motor controls the push/pull of the drill stem, and it's simple and convenient to operate.
Rotatable control panel: It widens the field of view and reduces operator fatigue.

Simple to operate: The rotation and push/pull of the power head is controlled separately, and it's simple and convenient to operate. The operator can master the operation skills through short-time training.

Model		XZ280
Engine		shangchai
Rated power	kW	140
Max.pullback/thrusting	kN	280/280
Spindle torque(max)	N.m	10000
Spindle speed	r/min	0-120
Backreaming diameter	mm	Ø750
Tubing length(single)	m	3
Tubing diameter	mm	Ø73
Entry angle	°	10-23
Mud flow rate(max)	L/min	250
Mud pressure (max)	bar	80
Overall weight	kg	12500
DIMENSION (LxWxH)	mm	7100×2260×2450
