Car Shock Absorber for Mercedes-Benz Sprinter (905) Truck Shock Absorber

Live chat with Seller

If you want to live chat with Seller ,Please - LOGIN to View Links.

Car Shock Absorber for Mercedes-Benz Sprinter (905) Truck Shock Absorber

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
100.0	US $ 0.1/ Piece

Price:US $0.1 / Piece

Trade Terms: FOB, CIF

Payment Terms: L/C, T/T, Western Union

Price Valid Time:From Jul 08, 2015 To Sep 17, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:905 320 00 30

Part:Dampers

Position:Front

Type:Gas-Filled

Spring Type:Coil Spring

Spring Material:Steel

Structure:Double Cylinder

Application:Mercedes-Benz

Brand:Gerep

Damping Force Direction:Bidirectional

Categories:Truck Spare Parts

Products:Shock Absorber

Location:Zhejiang, China

Painting Color:Customized Color Is Available

Painting Style:Shining or Matte

Packing Box:Customized Color Is Available

Engrave:Customized Design Is Available

Delivery Date:45~60 Days

Transportation:by Sea, Train or Air

Quality Guarantee:30000 Kms

Export Markets:Global

Additional Info.

Trademark:GEREP

Packing:Gerep Color Package and Customized Package.

Standard:TS/SGS 16949

Origin:Zhejiang

HS Code:870880100

Production Capacity:50000 PCS/Month

Product Description

TECHNOLOGY INTRODUCTION:

S/N.	Material speciation	Top quality
1	Piston Rod	The piston rod, larger in diameter to increase the strength, is hard-chrome plated, induction hardening , and fine polished for greater resistance to corrosion, thus, assuring of smooth action.
2	Oil Seal	The special Multi-slip oil seal, made of oil and wear-resistant high quality synthetic rubber, having high sealing efficiency to keep vital oil and gas in and dirt out of the cylinder.
3	Rod Guide	The sintered iron rod guide with a PTFE-bushed sliding surface, assures smooth rod action with minimal resistance and wear.
4	Nitrogen Gas	Nitrogen gas is filled in the reservoir except hydraulic type shock absorbers.
5	Rebound Stopper	A rebound stopper, made of a high quality synthetic rubber, or resin, is installed on the piston rod to act as the rebound stop.
6	Pressure Tube	The pressure tube, with a precision sliding surface mirror-like finish is designed to withstand tremendous internal working pressures, thus, providing greater reliability.
7	Piston Valve	Unique automatic control rebound disc valve, which automatically adjusts to all ride conditions, is designed to assure maximum performance and smooth ride control.It also provides instant response for full performance without any time lag.
8	Absorber Oil	Our absorber oil with constant viscosity, blended with chemical additives provide optimum operating performance keeping its efficiency, in any weather conditions.
9	Bottom Valve	Compression disc valve, which provides excellent performance, has automatic control actions similar to the rebound piston disc valve.

TRADE CONDITION:

1. RFQ - Request for quotation

We could identify shock absorbers by OEM No. or other brands part number which list following ( KYB, TOKICO, SACHS. BOGE, Bilstein, AL-KO, KONI, SABO, WEBCO, RECORD, MONROE, Gabriel, Cofap, Corven, NAKATA, Ultima, etc. )

Please send RFQ to our email to know our latest prices.

2. MOQ - Minimum order quantity

Our MOQ is 100 Pcs for each item, but if there are few items that we have in stock, the MOQ will not be indicated.

3. Customized brand packing box

We could accept customerized brand packing box based on MOQ 3000 pcs. If customerized brand order quantity less than 3000 pcs, a extra charge for printing box will be added in commercial invoice.

4. Delivery time: 45~60 days.

5. Payment term: 1> L/C 2> T/T

SHOCK ABSORBER SUIT FOR ALL MERCEDES-BENZ SERIES:

Application models for MERCEDES-BENZ truck	Year	OEM
ACTROS 1831 - 1860	04.96 -	006 323 16 00 006 323 33 00 006 323 39 00 006 323 40 00 006 323 74 00 005 323 96 00 006 323 73 00 007 323 14 00 958 323 08 00 958 323 09 00
ACTROS 2031 - 2055	04.96 -	006 323 33 00 006 323 39 00 006 323 40 00 006 323 74 00 005 323 96 00 006 323 73 00 007 323 14 00
ACTROS 2531 - 2560	06.96 -	006 323 39 00 006 323 40 00 006 323 74 00
ACTROS 2631 - 2660	04.96 -	006 323 16 00 006 323 33 00 006 323 39 00 006 323 40 00
ACTROS 3231 - 3336	06.96 -	006 323 33 00 006 323 39 00 006 323 40 00
ACTROS 3340 - 3360	06.96 -	006 323 60 00 006 323 78 00 006 323 79 00 357 323 00 00
ACTROS 4140 - 4160	06.96 -	005 323 97 00 006 323 21 00 006 323 72 00 375 323 01 00 958 323 05 00
ATEGO 1823 - 2628		006 323 54 00 006 323 65 00 006 323 71 00 958 323 06 00 958 323 07 00
ATEGO 712 - 717 712-1528		972 323 01 00 972 323 03 00 970 323 00 00 970 323 03 00 970 323 07 00 970 323 10 00 970 326 01 00 006 326 73 00
ATEGO 812 - 824	01.98-10.04	974 323 06 00 975 323 00 00
ATEGO 915 - 925	01.98-10.04	970 323 03 00 970 323 07 00 970 323 10 00
ATEGO 1015 - 1024	01.98-10.04	970 323 03 00 970 323 07 00 970 323 10 00
ATEGO 1214 - 1229	01.98-10.04	958 323 03 00 958 323 04 00 974 323 13 00
ATEGO 1317 - 1329	01.98-10.04	958 323 03 00 958 323 04 00 974 323 13 00
ATEGO 1517 - 1725	01.98-10.04	958 323 03 00 958 323 04 00 974 323 13 00
ATEGO 1823 - 1929	01.98-10.04	005 323 96 00 006 323 73 00 007 323 14 00 958 323 08 00 958 323 09 00 006 323 45 00 005 326 10 00
ATEGO 2223 - 2528	01.98-10.04	958 326 01 00 970 326 04 00 974 326 00 00 974 326 04 00
ATEGO 2628 -	05.98-09.04	006 323 16 00 006 323 33 00 006 323 39 00 006 323 40 00 006 323 74 00 005 323 97 00 006 323 21 00 006 323 72 00 375 323 01 00 958 323 05 00
AXOR 1823 - 2044	01.02 -	006 323 60 00 006 323 78 00 006 323 79 00 357 323 00 00 375 323 00 00
AXOR 2436 - 2543	01.02 -	005 323 97 00 006 323 21 00 006 323 72 00 375 323 01 00 958 323 05 00
AXOR 2623 - 2831	09.01 -	006 323 60 00 006 323 78 00 006 323 79 00 357 323 00 00 375 323 00 00
AXOR 3228 - 4144	09.01 -	006 323 60 00 006 323 78 00 006 323 79 00 357 323 00 00
SPRINTER 901,902,903,904	01.95 - 05.06	690 320 71 30 901 320 02 30 901 320 03 30 901 320 08 30 901 320 13 30 901 320 14 30 901 320 15 30 901 320 18 30 901 320 20 30 901 320 21 30 901 320 22 30 901 320 29 30 903 320 01 30 903 320 02 30
SPRINTER 906	01.95 - 05.06
T1 (601)	05.77 -02.96	601 320 00 30 601 320 01 30 601 320 07 30 601 320 02 30 601 320 03 30 601 320 04 30 601 320 04 31
SPRINTER (905)	01.95 -	905 320 00 30
Unimog		404 323 00 00 404 323 01 00 406 323 00 00 406 323 02 00
VARIO	09.96 -	004 323 88 00 004 323 89 00 005 323 02 00 005 323 03 00 005 323 09 00 005 323 19 00 004 326 06 00
VITO (638)	03.97 -07.03	638 320 07 13 638 320 08 13 638 320 09 13 638 320 10 13 638 320 11 13
206-5248		603 320 02 30 603 320 03 30 603 320 00 31

COMPANY INTRODUCTION:

We,Zhejiang Gerep Automotive Parts MFG Co., Ltd.,is a professional shock absorber manufacture.We manufacture different kinds of shock absorber,which suit for passenger car,truck,off road,coilovers etc.We pursue high quality and reasonable price. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.

GEREP SHOCK ABSORBER - CREAT VALUE FOR CUSTOMER
