Model No.: |
YT-M06-BM1 |
|
|
|
|
Car Makes |
Model |
Model Year |
Head Unit |
CDC Connector |
|
BMW |
3 Series E36 |
1991-1998 |
Business, Professional |
|
|
3 Series E46 |
1998-2005 |
Business, Professional
Navigation 4:3 |
|
5 Series E39 |
1996-2000 |
Business, Professional
Navigation 4:3, 16:9 |
|
7 Series E38 |
1994-2001 |
Business, Professional
Navigation 4:3 |
|
E36 Compact |
1993-2000 |
Business |
|
E46 Compact |
1994-2006 |
Business |
|
X3 E83 |
2004-2006 |
Navigation 4:3 |
|
X5 E53 |
2001-2006 |
Navigation 4:3 |
|
Z3 |
1996-2002 |
Business |
|
Z8 E52 |
2001-2002 |
Business, Business CD,
Navigation 4:3 |
|
Motorrad K1200LT |
1997-2004 |
Business 2000,Professional 2000 (by Becker) |
|
BMW R1200LT |
1997-2004 |
Professional 2000 (by Becker) |
|
MINI R5x |
2001-2006 |
Wave Cassette |
|
Land Rover |
Range Rover L322 |
2002-2004 |
|
|
Rover |
Rover 75 |
1999-2005 |
Navigation 4:3(by Alpine/VDO) |
|
Specific Notes: |
|
1, Compatible Head unit: BE3350 (Business cassette), BE3351(Business cassette), BE6510 (Professional), BP8272 (Business CD) , BP9272 (Business CD), PH7050 (Business cassette), PH7070 (Businesscassette), PH7090 (navigation system), PH7860T (Business RDS), PH7950(Business cassette), PH8060 (Business CD), PH9860 (BUSINESS CDRDS), Autoradio(not DSP), BordMonitor,BMW with monitor(not DSP), Business CDRDS, navigation system, car radio with the 17 pins round connector |
|
2. Not compatiblewith BMW cars with DSP(Digital Signal Processor) or Reverse RDS radios. |
|
3. Not ableto combine with existing CD Changer, CD Changer must be disconnected. |
|
4. Not compatiblewith BMW radios without i-Bus (up to 1997) |
|
5, Supports ID3 tag(text display) on text capable radio. |
|
6, On BMW motorcycle K1200LT/R1200LT models, extra 12V ACC power supply to Yatour may be necessary |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Model No.: |
YT-M06-BM2 |
|
|
|
|
Car Makes |
Model |
Model Year |
Head Unit |
CDC Connector |
|
BMW |
3 Series E46 |
1998-2005 |
Business, Professional
NOTsupport Navigation system |
|
|
5 Series E39 |
2000-2003 |
|
7 Series E38 |
1994-2001 |
|
E46 Compact |
2000-2004 |
|
X3 E83 |
2004-2006 |
|
X5 E53 |
2001-2006 |
|
Z4 E85 |
2002-2008 |
Business, Business Navigation, Professional Navigation |
|
Z8 E52 |
2002-2003 |
Business, Business CD |
|
Range Rover |
2003-2004 |
Without Navigation |
|
MINI R5x |
2001-2006 |
BOOST, Harman Kardon |
|
Specific Notes: |
|
|
|
|
1, Compatible head unit: BE6507(E39 BMW Business), PH7030(BMWBusiness), PH8030(BMW Business CD), CD53 E39/53 Part Number 65. 12-6 908 783 (BMW Business CD,Alpine), etc |
|
2. Not compatiblewith BMW cars with DSP(Digital Signal Processor) or Reverse RDS radios or i-Drive system. |
|
3. Not able to combine with existing CD Changer, CD Changer must be disconnected. |
|
4. Not compatiblewith Alpine CD53 R50 radio, Alpine BMW CD53 E46 radio, BMW 16:9 Navigation radios. |
|
5. Not compatiblewith BMW Business Multi-Info-Radio with Navigation. |
|
6. Not supportBMW Navigation system. |
|
7, SupportsID3 tag(text display) on text capable radio, requires to disconnect 3pin plug and 6pin plug of CD changer connection in trunk. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Model No.: |
YT-M06-BM4 |
BMW Trunk Interface Kit |
|
|
Car Makes |
Model |
Model Year |
Head Unit |
CDC Connector |
|
BMW |
3-Series E46 |
1996-2005 |
All except Navigation system |
|
|
5-Series E39 |
1997-2003 |
|
7-Series E38 |
1998-2001 |
|
X3 |
2004-2010 |
|
X5 E53 |
2000-2005 |
|
Z3 |
1997-2002 |
|
Z4 |
2003-2005 |
|
M-Roadster |
1999-2002 |
|
M-Coupe |
1999-2002 |
|
Mini |
2001-2005 |
|
M3 |
1997-2005 |
|
M5 |
2000-2003 |
|
Z8 E52 |
2000-2003 |
|
Ranger Rover without Navigation |
|
Specific Notes: |
|
|
|
|
1. All BMW cars MUST be pre-wired for factory CD changer. |
|
|
|
|
|
Remarks:
YATOUR and the CD Changer cannot be used at the same time. |
|
2. NOT supportBMW cars with OEM Sirius. |
|
3. Not support BMW Navigation system. |
|
4, For BMW with BM52/BM53/BM54 modules in trunk, users have to directly connect red ACC wire of Yatour to radio back or the antenna power output of BM5X module. |
|
5. If some BMW cars are equipped with DSP (Digital Signal Processor), additional DSP Kitis required. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Beforeinstalling the DSP Kit, |
1. Make sure to disconnect your car battery. Failure to do so might result in damage to electrical components.
YATOUR Digital Music Changer may not function or will function improperly if the battery is not disconnected before installation. Disconnectin |
|
2. Check to see if your car has DSP. |
|
To see if your car has DSP, look for a bare metal coax cable and a 3-pin connector. If you do not find a coax cable but find a 6-pin connector along with a 3-pin connector, your car does not need this DSP Kit. |
|
If you have a factory CD Changer installed, check the connections for a 3-pin and coax input. If it has a 3-pin and a 6-pin input, your car does not need this DSP Kit. |
|
Model No.: |
YT-M06-FA |
|
|
|
|
Car Makes |
Model |
Model Year |
Head Unit |
CDC Connector |
|
Alfa Romeo |
147 |
2000-2011 |
Blaupunkt 376 / 378 / 379 / 937 / 947 |
|
|
156 |
1997-2005 |
Blaupunkt 376 / 378 / 379 / 937 / 947 |
|
159 |
2005 -2011 |
Blaupunkt 376 / 378 / 379 / 937 / 939 / 947 |
|
Brera |
2005-2011 |
Blaupunkt 939 |
|
GT |
2004 -2011 |
Blaupunkt 937 |
|
MiTo |
2008-2010 |
|
|
Giulietta |
2010 |
Non Navigation |
|
Spider |
2006-2011 |
Blaupunkt 939 |
|
Fiat |
Bravo |
2005-2007 |
Blaupunkt OEM radio, Connect Nav+ ( Magneti Marelli), Lancia 843 CD,Lancia 848 MP3 SB03, FIAT 312 MP3 SB05, Blaupunkt 169, Delphi F199, Blaupunkt CDC-A08 |
|
New Bravo |
2007-2010 |
|
Coupe |
1995 + |
|
Croma |
2005-2010 |
|
Ducato |
2006-2010 |
|
Doblo |
2001-2010 |
|
Idea |
2004-2010 |
|
Multipla |
2000 + |
|
Qubo |
2000 + |
|
Punto CC DA |
2003 + |
|
Panda |
2004 -2010 |
|
Punto |
1999 -2010 |
|
Punto EVO |
2010 + |
Delphi/Blaupunkt |
|
Stilo |
2002 + |
Visteon/Blaupunkt |
|
Fiat 500 |
2007-2011 |
|
|
Lancia |
Musa |
2004-2011 |
Blaupunkt OEM radio, Connect Nav+ ( Magneti Marelli), Lancia 843 CD,Lancia 848 MP3 SB03, FIAT 312 MP3 SB05 |
|
Lybra |
1999-2005 |
|
Thesis |
2002-2008 |
|
Delta |
2008-2011 |
|
Phedra |
2002-2011 |
|
Ypsilon |
2003-2012 |
without ICS system |
|
Specific Notes: |
|
1. Compatible with Blaupunktfactory radios with 8-pin CD changer connection. |
|
2. Notcompatiblewith Navigationsystem headunits. |
* Blaupunkt Rome NAV55E
* Connect Nav+
* Magneti Marelli Connect Nav+
* TravelPilot |
3.Not compatible with :
FIAT 312 MP3 AUX 2 PLUS(Bosch), ALFA 940 LOW PLUS AUX 2, Lancia 846 SB08 Plus ( Bosch), Fiat 139 MP3(Continental) |
|
4.Not work with Fiat/Alfa/Lancia with OEM Becker/Grundig/Bosch/Continental radios |
|
5.Not work with RD3 Van-bus radios |
|
6.Not suitable for Fiat/Alfa/Lancia with ICS(integrated control system) system |
|
7. Not guaranteecompatibility with Visteon factory radios. |
