Description

Details

Basic Info.

Model NO.:TA13058BO 0120300558 1-1557-01BO 0120300528

Type:Alternator

Structure:Magneto Alternator

Current Level:3(30?39A)

Bonding Type of Magnetic Field Winding:Inner Bonding

Brushless Alternator Type:Permanent Magnet Type

Voltage Adjuster Type:Electronical

Voltage:12V

Head Cover Position:Front

Brand:Bosch

Peremeter:12V 33A Er/Ef Cw V1

Export Markets:Global

Additional Info.

Trademark:Trans-Sen

Packing:Carton & Pallet

Origin:Shanghai

HS Code:85115090

Production Capacity:20000 Per Year

Product Description

TYPE Alternator
MFR BOSCH
DESIGN ER/EF
VOLTAGE 12
AMPERAGE 33
ROTATION CW
PULLEY DESIGN V1
PULLEY OD77
PLUG CLOCK10
PLUG CODE112

COMPANY NO	TA13058BO
LESTER	13058
BOSCH	0-120-300-527
BOSCH	0-120-300-528
BOSCH	0-120-300-529
BOSCH	0-120-300-551
BOSCH	0-120-300-558
BOSCH	0-120-300-568
BOSCH	0-120-300-569
BOSCH	0-120-300-746
CARGO	110899
CARGO	110900
DIXIE	A-651
EXCEL	13058
FIAT	4224325
FIAT	4257063
FIAT	4257074
FIAT	4257771
FIAT	4275283
FIAT	4325179
LESTER (OLD)	13130
LESTER (OLD)	14053
MPA	13058
NAPA	13-8055
USA INDUSTRIES	A608
WAI	1-1557-01BO
WILSON	90-15-6283
WILSON HD	90-15-6283

DESCRIPTION:
This Looks Similar to the Marelli 14045. The Difference is That the 13058 Uses a White 3-Prong Plug Brushholder Along With a 2nd 2-Prong Plug on the Rectifier. The 14045 Will Not Interchange.

APPLICATION:
FIAT 1973-74
FIAT TRACTOR 1973-84
1-V PULLEY 77mm OD
SEARCH: 486530 (MARELLI)
