Asme LPG Gas Trailer Tri Axle Liquid Gas Trailer 25ton Propane Gas Trailer

Live chat with Seller

If you want to live chat with Seller ,Please - LOGIN to View Links.

Asme LPG Gas Trailer Tri Axle Liquid Gas Trailer 25ton Propane Gas Trailer

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 29600.0-37600.0/ Piece

Price:$29600.0 - $37600.0 / Piece

Trade Terms: FOB, CFR, EXW, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA

Payment Terms: L/C, T/T, D/P, Western Union, Paypal, Money Gram

Price Valid Time:From Dec 24, 2014 To Mar 24, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:clw9400GYQA

Function:Storage Pressure Vessel

Application:Liquefied Gas

Material:Carbon Steel

Pressure:1.6MPa?p<10.0MPa

Storage Medium:Flammable/Toxic

Pressure Level:Medium Pressure (1.6MPa?p<10.0MPa)

Condition:New

Medium:Propane Gas Isobutane Methypropane Liquid Ammonia

Fitter:Dimethyl Ether Dme Propylene Propene Pgp

Volume of Tanker:40cbm 45cbm 50cbm 56cbm 60cbm 59.52cbm 58.5cbm

Tank Material:Q345r Q370r

Capapcity:25ton 25t 25000kg 17ton 17t 17000kg

Thickness of Tanker:8mm 13.5mm 10mm 11mm 12mm 11.5m

Product:Asme LPG Gas Trailer Tri Axle Liquid Gas Trailer 2

Shape of Endplate:Round, Ellipse, Sphere

Axle Brand:BPW or Fuwa

Design Pressure:1.91MPa 1.15MPa 1.61MPa 0.70MPa

Export Markets:Global

Additional Info.

Trademark:CLW

Packing:Naked, RO-RO, Bulk. Container

Standard:CCC, ISO9001, ISO14001

Origin:Hubei Suizhou

HS Code:87163910

Production Capacity:500units/Month

Product Description

ASME Lpg gas trailer tri axle liquid gas trailer 20ton 25ton 30ton propane gas trailer

Specifications---

1. LPG Semi trailer LPG gas trailer LPG tank trailer LPG tanker trailer
2. LPG storage tank
3. Tri Axle 2 axle 4 axle lpg gas trailer liquid gas trailer propane gas trailer lpg tank trailer lpg tank gas trailer
4.40 CBM, 45CBM. 50CBM, 60CBM lpg gas trailer liquid gas trailer propane gas trailer lpg tank trailer lpg tank gas trailer
5. Certification: ISO9001 CCC,SGS,ASME lpg gas trailer liquid gas trailer propane gas trailer lpg tank trailer lpg tank gas trailer

Asme LPG Gas Trailer Tri Axle Liquid Gas Trailer 25ton Propane Gas Trailer

LPG trailer brief---

1)Designing pressure: 1.61MPa Designing temperature: -20C-50C
2)The various types LPG tanker is researched and manufactured by stress analysis design and has obvious advantage of large capacity. Light weight and high efficiency.
3)We inspect the quality of product strictly, ensure that A and B type of welding seam pass the examination of level two radiographic test, C and D type of welding seam pass the examination of level one radiographic test.
4)There are domestic or imported safety accessories with high quality, its matching is complete.
5)The anticorrosion coating of LPG tanker adopt the following process, sandblast, spray painting, purging and so on

Strict Manufacturing Procedures---
Asme LPG Gas Trailer Tri Axle Liquid Gas Trailer 25ton Propane Gas Trailer

About our company----

LPG tank LPG gas trailer LPG tank trailer LPG tanker trailer is our most advantage key products which rank Top 5 in China, excellent engineers and high-grade production equipment as well as stricted quality control system can ensure all the tank from us run very well with 10-20 years use life.

Competitive Price and Excellent Quality,
More than 10 years' experience as a manufacturer
CCC,ISO,BV certification
Perfect after-sale service
Customized products available with us,
Export covering More than 50 countries and regions
Annual production value topped 1500,000,000 RMB (240,000,000 US dollars) per year

Our main products---
1. Dump Truck / Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck mounted crane
4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5. Water truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
LPG tanker trailer brief Introduction

Cheng Li produced a liquefied gas storage tanks in series, can be used to store the different nature of the liquefied petroleum gas (propane), propylene, ammonia, dimethyl ether, methanol, butadiene, butane, ethylene oxide, methylamine, etc. In low pressure liquefied gases at room temperature; Volume from 10 cubic meters --- 100 cubic optional.
Chengli pressure components of the productIion materials, size and weld quality, operation quality, installation quality, safety valves and shut off valves devices and accessories within the strict qualification, inspection, test. The tank materials on physical and chemical tests such as: Mechanical properties and chemical composition.

The tank welded joints, welding line, tank head, the pressure of the geometric location of each component through rigorous X-ray non-destructive testing and magnetic particle testing inspection.
Seal on the product, pressure, and those who can affect the operation of product safety testing various technical indicators.
A, B Class 100% ray weld inspection, II level qualified
C, D Class welds 100% magnetic particle inspection, I level qualified

Item			Unit	Parameter
Product name				ASME Lpg gas trailer tri axle liquid gas trailer 25ton propane gas trailer
Practical capacity			M3	59.52
Gross weight			kg	40000
Curb weight				1 5 000
rated loading capacity				25000
Overall dimension			mm	1 3000 2 500 39 90
Axle				3
Wheelbase				7230 +13 10 +13 10
Tread	Front tread			-
	Rear tread			1840/1840/1840
Front/rear suspension			mm	-/1745
Leaf spring				-7/7/7
Fifth wheel max loading			kg	16000
Tyre specification				12.00-20
Exclusive configuration		Tank material	Q345R Q370R
		Standard configuration	13T BPW or FUWA axle, safety valve,single fluid two valve box.hydraulic legs,traction pin,liquid Indicator,pressure gauge,temperature gauge,emergency cut-off valve,valve box,fire suppression bottle,spark hider cover,anti static grounding tape,protective guard,tyre protective shield.
		Other	Filling Medium: propane :design pressure 2.16Mpa,design temperature 50°C,filling ratio:0. 42 t/m3,corrosion allowance:1mm:dimension of tank:1 2837 * 11.5*2475 mm .
		Standard configuration	GB1501998,Supervision regulation on safety technology for pressure vessel,Supervision regulation on safety technology for Liquefy gas tank truck.
