Ample Lighting Down Draft Furniture Spray Booth

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:$7200.0 - $9360.0 / Set

Min. Order (Sets)	Unit Price
1.0	US $ 7200/ Set
5760.0	US $ 9360/ Set

Trade Terms: FOB, CFR, CIF, EXW

Payment Terms: L/C, T/T, Cash

Price Valid Time:From Aug 13, 2014 To Nov 13, 2014

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:YS-4000-PR

Certification:CE

Airflow Direction:Semi Downdraft Airflow Way

Heating Mode:No Heaters

Paint Mist Treatment:Dry-type

Condition:New

Ventilation:Semi Downdraft Airflow Way

Air Exhaust:Axial Fan

Voltage:1X220V, 3X380V, Your Special Voltages Are Accepted

Optional Colour:White, Blue, Orange and Red

Port:Huangpu Port or by Your Order

Main Product:Spray Booth, Prep Station, Infrared Curing System

Export Markets:Global

Additional Info.

Trademark:YOKISTAR

Packing:Bubble Film Packing for Sea Transportation in Bulk

Standard:20?GP can load 1 set, 40?GP 3 sets, 40`HQ 4 sets

Origin:Guangdong, China

HS Code:84198990

Production Capacity:120units/Month

Product Description

Model:YS-4000-PR
Inside dimention:8080*3940*2700mm L*W*H
Any Size Requirements Can Be Met.
Applied for furniture spraying

A. During painting, spray booth can offer a sealed environment with cleanness, safety and excellent lighting for the painting operation of all kind of components and different products.
B. During baking, drying time, temperature and humidity in spray booth can be set according to different paint materials to achieve a perfect high-quality spraying and baking for your cars.
C. Spray booth makes spraying and baking operation with no limits of all kinds of whether, thus ensuring physical fitness of operators and absolute safety of equipments.

Warranty
The goods are guaranteed for 24 months from the date of receipt, but the filters and lamps are not guaranteed. It cannot be applied for damages caused by negligence of operations or mishandling of the machine.

YOKISTAR Products

High quality and advanced technology are applied in YOKISTAR product ranges, involving automotive spray booth, bus and truck spray booth, prep station, mixing room, bench spray booth, open face spray booth and infrared curing lamp.

Inside Dimension	8080в 3940в 2700 mm ( Lв Wв H )
Outside Dimension	8180 в 4040 в 3100 mm ( Lв Wв H )
Main Door	Drive thru, 2 units main doors, 3 folds/unit, 2840в 2650mm(Wв H), color: blue.
Escape Door	1 unit, 700в 2000mm(Wв H), color: white.
Room Body	Wall panels and roof panels are double skinned, tongue and groove structure, thickness: 50mm, made by 0.376mm color steel with polystyrene(EPS) inside, color: white.
Lighting System	Ceiling lights: 10unitsв 4pcs=40pcs36W, with electronic ballasts. Side lights: 6unitsв 4pcs=24pcs36W, with electronic ballasts.
Exhaust Air System	Exhaust air from top, axial fan, air capacity: 12000 m3/h. Exhaust air cabinet installed in the corner of back side wall panels. Galvanized steel molding frame with exhaust air filter
Filtering System	Pre-filter, exhaust fiberglass filter.
Control System	Power supply switch, fan operation and lighting switch.
