Description

Details

Basic Info.

Model NO.:QDT5250ZYSE

Type:Compression

Certification:ISO9000, CCC, TS16949

Volume:10001-15000L

Emission Standard:Euro 4

Transmission Type:Manual

Engine Type:2 Stroke

Payload:10t

Fuel:Diesel

Drive Wheel:6×4

Brand:Dongfeng

Models:Large

Usage:Compression Type

Chassis:Dfl3250A9

Condition:New

Chassis Model:Dfl3250A9

Engine Type/Cc(Ml):Isde230 30

Rated Power(Kw):169

Loading Capacity(Kg):11645, 11345

Curb Weight(Kg):13160, 13460

Gross Weight(Kg):25000

Wheel Specification:11.00-20

Tank Volume(Cbm):15

Hydraulic System Rated Power(MPa):19

Filling Time(S):25

Export Markets:Global

Additional Info.

Trademark:Qingte

Packing:Nude Packing

Standard:SGS

Origin:Qingdao, Shandong, China

HS Code:8716

Production Capacity:12, 000/Year

Product Description

Qingte 6X4 Compression Garbage Truck
QDT5131ZYSE

Key Features:

1. Arc-shaped Side Plate structure and Frame Structure optional

2. Adopting high strength wear-resisting plate for loading device to sustain repeatedly impaction and friction.

3. Key components like guide rail are all machined parts equiping high-tech nylon ensuring precision and steady.

4. With help of Double Pump and Double Circuit System, working life is raised and energy consumption has been reduced.

5. Adopting imported multitandem valve for compressing, realizing stable two-way compression.

6. Compressing system has both single cycle and auto-continuous compressing loop.

Model	QDT5131ZYSE
Chassis Model	DFL3250A9
Engine Type/cc(ml)	ISDe230 30
Rated Power(kw)	169
Loading Capacity(kg)(kg)	11645,11345
Curb Weight(kg)	13160,13460
Gross Weight(kg)	25000
Max Speed(km/h)	81
Wheel Specification	11.00-20
Dimension(L/W/H)(mm)	8820,9120X2500X3035
Wheel Base ( )	3650+1350
Overhang(Front/Rear) ( )	1465/2360,1460/2660
Approach Angle/Departure Angle ( )	30/16
Tank Volume(m³)	15
Filling Volume( )	2.2
Hydraulic System Rated Power(Mpa)	19
Filler Opening Lower Edge Ground Clearance(mm)	1200
Filling Period( )	25
Garbage Unloading Time( )	45
Waste Water Tank Volume(L)	?400
Mechanical Hand Tipping Quality(kg)	?600
Garbage Compression Density(kg /m 3 )	?800
