4X2 Sealed Type Dump Garbage Truck (QDT5122ZLJE)

Live chat with Seller

If you want to live chat with Seller ,Please - LOGIN to View Links.

4X2 Sealed Type Dump Garbage Truck (QDT5122ZLJE)

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 30000/ Piece

Price:US $30000.0 / Piece

Trade Terms: FOB, CFR, CIF, DDP, DAP, FCA, EXW

Payment Terms: L/C, T/T

Price Valid Time:From Oct 06, 2014 To Jan 06, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:QDT5122ZLJE

Type:Dump Type

Certification:ISO9000, CCC, TS16949, CE

Volume:10001-15000L

Emission Standard:Euro 4

Transmission Type:Manual

Engine Type:2 Stroke

Payload:6t

Fuel:Diesel

Drive Wheel:4×2

Brand:Dongfeng

Models:Single Bridge

Usage:Dump

Chassis:Dfl1120b3

Condition:New

Chassis Model:Dfl1120b3

Engine Type/Cc(Ml):Isde180 40(Optional)

Rated Power(Kw):132

Loading Capacity(Kg):5760

Curb Weight(Kg):6540

Gross Weight(Kg):12495

Wheel Specification:9.00-20(Optional)

Tank Volume(Cbm):12

Hydraulic System Rated Power(MPa):16

Filling Time(S):25

Export Markets:Global

Additional Info.

Trademark:Qingte

Packing:Nude Packing

Standard:SGS

Origin:Qingdao, Shandong, China

HS Code:8716

Production Capacity:1000/Year

Product Description

Sealed type Dump Garbage Truck is one set of special equipment for environmental. It is adopted our large advanced technique of refuse compression. Equipment electrical and hydraulic components are well-known international brand, with a long product life, low failure rate.Fully sealed design tank body and a large capacity sewage slot on the rear bottom, to avoid sewage leakage pollution during transportation; This vehicle will mainly meet the need of refuse processing in small-medium cities and large towns

Model	QDT5122ZLJE
Chassis Model	DFL1120B3
Engine Type/cc(ml)	ISDe180 40(Optional)
Rated Power(kw)	132
Wheel Specification	9.00-20(Optional)
Loading Capacity(kg)	5760
Curb Weight(kg)	6540
Gross Weight(kg)	12495
Max Speed(km/h)	100
Dimension(L/W/H)(mm)	6485X2480X2880
Wheel Base ( )	3650
Wheel Track(Front/Rear) ( )	1880/1800
Overhang(Front/Rear)	1430/1405
Approach Angle/Departure Angle (°)	20/24
Tank Volume(m³)	12
Hydraulic System Rated Power(Mpa)	16
Tank Lifting Angle (°)	48±2
Filler Opening Lower Edge Ground Clearance(mm)	Appr.1350
