40-45ft Container Flat Bed Semi Trailer with 2axles or 3 Axles

Live chat with Seller

If you want to live chat with Seller ,Please - LOGIN to View Links.

40-45ft Container Flat Bed Semi Trailer with 2axles or 3 Axles

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 16800/ Piece

Price:US $16800.0 / Piece

Trade Terms: FOB, CFR, CIF

Payment Terms: L/C, T/T

Price Valid Time:From Apr 01, 2015 To Jun 03, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:FTW9300ZTP

Type:Axle

Load Capacity:30T

Certification:ISO9001, CCC, SGS

Wheel Base:7000-8000mm

Tread:2240mm

Grade:Light Duty

Towing Pin Material:Carbon Steel

Impeller Type:Closed Type

Hook Type:Single

Universal Joint Type:Rigid Universal Joint

Brake Pad Material:Semimetal

Towing Pin Type:Cross Type

Towing Pin Diameter:50mm

Differential Gear Type:Gear Type

Independent Suspension Type:Cross Arm Type

Connecting Type:Semi-trailer

Shape:Van-type

Axle Number:3

Tire Number:12

Self-dumping:Self-dumping

ABS Anti-lock Braking System:ABS Anti-lock Braking System

Material:Steel

Condition:New

Payload:30t

Export Markets:North America, South America, Southeast Asia, Africa, Mid East, Eastern Asia

Additional Info.

Trademark:jupiter

Packing:Nude or as Customer?s Requirement

Standard:12480*2480*1500

Origin:China

Production Capacity:1000PCS Per Year

Product Description

40-45ft Container Flat Bed Semi Trailer with 2axles or 3 Axles

Packaging & Delivery

Packaging Detail: Roro, bulk shipment or container shipping

Delivery Detail: 20 DAYS

Specifications

For 40-45ft nonstandard container. And other goods

DIMENSIONS

Tare Weight

6500kg

Payload

35000kg

Total Weight

42000kg

Overall Length

12480mm

Overall Width

2480mm

Overall Height

1500mm

Wheelbase

1360mm

SPECIFICATION

Main Frame

Heavy duty and extra durability designed; Choose high tensile steel Q345B, welded by automatic Submerged arc processes.

12PCS twistlocks

Floor

Steel Sheet 3mm thickness

Axle

3x13Ton L1 Brand axle

Suspension

Mechanical Suspension 6sets leaf spring

Kingpin

2" standard kingpin---JOST brand

Landing Gear

1 pair landing gear---JOST brand

Wheel Rim

12units 8.0" rims

Tyre

12units 11.00R20

Spare Wheel Carrier

One set of spare wheel carrier including a riser

Pneumatic

Braking System

Double line air brakes Mechanical parking brake,

Electrical

System

24V system with standard 7 pole plug

Rear electrical lighting, brake lights, indicators, fog lights and reversing light

Painting

Sand blasting before painting. One coats of primer, anti corrosion. Two
