30 Tons Mobile Crane Good Price QY30K5-I

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 150000/ Piece

Price:US $150000.0 / Piece

Trade Terms: FOB, CFR, EXW, CIF, DAT, FAS, DDP, DAP, CIP, CPT, FCA

Payment Terms: L/C, T/T, D/P, Western Union, Paypal, Money Gram

Price Valid Time:From Mar 28, 2014 To Jun 28, 2014

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:QY30K5-I

Max. Lifting Height:48.7m

Max. Lifting Load:30t

Max. Travel Speed:80km/H

Max. Gradeability:40%

Rated Lifting Moment:1025kn. M

Engine:Sc8dk280q3/Wd615.329

Feature:Hydraulic Crane

Color:Golden Yellow

Overall Dimensions(Lxwxh):12570X2500X3390mm

Export Markets:Global

Additional Info.

Trademark:XCMG

Packing:Standard Export Seaworthy Packaging

Standard:CE, ISO Standard

Origin:Jiangsu

HS Code:8426411000

Production Capacity:30 Sets Per Month

Product Description

30 tons mobile crane good price QY30K5-I

1. Max. Loading: 30t
2. Engine: 211kw SC9DF290Q4
3.5 section boom 40.4 m
4. Jib 8.3 m
5. Hirschmnn moment limiter

Features of 30T XCMG Truck Crane QY30K5-I:

(1) The innovative jib system adopts embedded block, plug-in boom head and octagon jib, which has excellent lifting performance and safe and reliable lifting work.
(2) The unique stretch and retract technique avoids the bend of the core pipe and cylinder and the break of the boom caused by misoperation, improving the safety of the operations.
(3) Eight patent techniques ensure the smooth, high efficiency and energy conservation of the lifting, rotation, and luffing systems.
(4) The torque limiter adopts colorful LCD display, realizing the intelligence of the failure diagnosis. The precision is ahead of the industry.
(5) Adopt the new hydraulic motor with big torque starting point, making the secondary lifting safer.
(6) The humanity design makes the cab and control cab more spacious, and easy to operate.
(7) Six unique manufacturing technologies ensure the high quality.
(8) Extend the lifting space and scope, greatly improving the lifting capacity of the front part.

Parameters of 30T XCMG Truck Crane QY30K5-I:

Dimension	Unit	QY30K5-I
Overall length	mm	12570
Overall width	mm	2500
Overall height	mm	3390
Weight
Total weight in travel	kg	32400
Front axle load	kg	7000
Rear axle load	kg	25400
Power
Engine model		SC8DK280Q3	WD615.329
Engine rated power	kW/(r/min)	206/2200	213/2200
Engine rated torque	N.m/(r/min)	1112/1400	1160/1400
Travel
Max. travel speed	km/h	80
Min. turning diameter	m	22
Min. ground clearance	mm	291
Approach angle	°	19
Departure angle	°	13
Max. grade ability	%	40
Fuel consumption for 100km	L	40
Lifting Performance
Max. rated total lifting capacity	t	30
Min. rated working radius	mm	3000
Turning radius at turntable tail	m	3.065
Max. lifting torque	kN.m	1025
Base boom	m	10.6
Fully extended boom	m	40.4
Fully extended boom+ jib	m	48.7
Longitudinal outrigger span	m	5.85
Lateral outrigger span	m	6
Working speed
Boom luffing time	s	68
Boom full extension time	s	150
Max. swing speed	r/min	2.5
Max. speed of main winch (single rope) (no load)	m/min	120
Max. speed of aux. winch (single rope) (no load)	m/min	120
