3 Axles Bulk Concrete Cement Semi-Trailer 50ton

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:

Min. order:1 Piece

Trade Terms:FOB, CFR, CIF, EXW

Payment Terms:L/C, T/T

Trademark:CIMC

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:ZCZ9400GFL

Type:Semi-Trailer

Certification:ISO

Material:Steel

Scale:Heavy Duty

Components:Trailer Suspension

Load Capacity:50T

Export Markets:Global

Additional Info.

Trademark:CIMC

Packing:Nude Packing

Standard:International standard

Origin:Shandong, China

Production Capacity:60000 Units/Month

Product Description

3 Axles Bulk Concrete Cement Semi-Trailer 50ton

Products advantages

--The tank body is one-time formed by two-face welding and is one-time rolled by large plate splicing machine, featuring beautiful shape and high reliability. There are multiple capacities of tank body to meet the individual demands from different customers

--Depending on the characteristics of the powder materials(such as granularity, density, and viscosity), the patented fluidization structure is adopted within the tank body. Differing from fluidization structure of common powder tank, the patented fluidization structure is calculated and set in terms of fluidization area, fluidization angle, breathe resistance, and airflow rate, featuring simple structure, easy maintenance, good fluidization performance, and more suitability to the fluidization of powder material.

--Based on the characteristics of the powder materials, the tank body is internally equipped with separation-proof device and blockage-proof device to fully resolve the separation issue of powder materials during the transport, pneumatic delivery, and unloading process, guarantee the quality of materials being transported, and thus ensure that all indexes of the powder material meet the operation requirements.

--The pipeline system is fitted with reasonable auxiliary blower and anti-wear device to realize smoother unloading process, faster unloading speed, and longer service time.

--The tank body adopts the specially customized high strength special steel, featuring light dead weight and high strength and building maximum operation value for the customers

Item No.	ZCZ9400GFL 3 Axles Bulk Concrete Cement Semi-Trailer 50ton	Batch	240
Brand	CIMC	Type	Low density bulk cement semi-trailer
Rated weight	60800/60700	Total Weight(kg)	73000
Curb weight(kg)	1220012300	Axles' Quantity	3
Axle base(mm)	5100+1310+1310	Axle load	24000(3 axles installed side by side)
Q'ty of the steel plate spring	-/7/7/7,-/10/10/10	Tyre Quantity	12
Tyre size	11.00R20 12PR,11R22.5 12PR,12R22.5 12PR	Approach/Departure angle	-/21
Front/rear suspension(mm)	-/1780	Overall length	11000/10100
Wheel base(mm)	1820/1820/1820,1840/1840/1840	Overall wide	2500
Max loading of the saddle	16000	Overall height	3995
Remark	Tank dimensions: front diameter is 2016mm, end diameter is 2496mm, the straight section length is 9120mm (not contain two head), the effective volume is 47.5 cubic meters, the transport medium: fly ash, density is 650 kg / m3.ABS model: CM2XL-4S/2M, later protection section height / section width/ height: 140mm/70mm/530mm, side protective material / connection: Q345 / back protection welding side protection bolt connection. Optional supporting wheel plate and the rear structure.


Popular models


	38 m³ cement tank semi-trailer single tire	44 m³ cement tank semi-trailer single tire	50m³ cement tank semi-trailer single tire	70 m³ cement tank semi-trailer single tire
Model	ZCZ9402GFLHJB	ZCZ9403GFLHJB	ZCZ9404GFLHJC	ZCZ9400GFLHJA
Overall dimensions(mm)	10100,920025003900	10815, 987525003900, 4000	10115, 1086525003995	1300025003995
Nominal capacity	38 m³	44 m³	50m³	70 m³
Number of axle	3	3	3	3
Wheelbase(mm)	5100+1310+1310	5100+1310+1310	6100+1310+1310	8670+1310+1310
Noninal front/rear suspension	1500/880 600/880	1550/1545, 610/1545	500/895, 250/895	500/1210
Bearing capacity (kg)	31000 31800	30350, 31150	31000, 30200	27500
Curb weight (kg)	8900 8100	9600, 8800	9000, 9800	12300
Number of leaf spring plate	4\ 7 \ 10	7\ 10\ 12	7\ 10\ 12	12\ 10
Remarks	Single-row wheels	Transport medium:	Transport medium:	Transport medium:
	Three axles	Dry coal ash, with density at 710kg/m³.	coal ash, with density at 630kg/m³	soft coal powder, with density at 410kg/m³
	six sets of tires	Optional front installation mode of
	Transport medium:	diesel engine and air compressor.
	anthracite duff, with density at 850 kg/m³
