3 Axles, 60tons Cement Tanker Semi Trailer

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (unit)	Unit Price
1.0	US $ 28000/

Price:US $28000.0 / unit

Trade Terms: FOB, CFR, CIF, EXW

Payment Terms: L/C, T/T

Price Valid Time:From Aug 01, 2013 To Nov 01, 2013

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:CTY60JZ

Size Can Be Choose Freely:We Do The Trailer According to The Customer Requir

Components:Whole Trailer

Export Markets:Southeast Asia, Africa, Mid East, Western Europe

Additional Info.

Trademark:TONGYA DA BRAND

Packing:Nake

Standard:10000*2500*3850MM

Origin:Liangshan, Shandodng of China

HS Code:87163190

Production Capacity:5000PCS Per Year

Product Description

3 axles, 60tons V type tanker semi trailer
Main Dimensions
Tank Body
Shape: Optional ( One Silo with V type or Two, Three Silos Design)
Dimension: 12000mm*2490mm*3990mm ( Exact size depends on the final design)
Tare weight: About 13000KG Total Volume(m3): 60 m³
Tanker Body: Material5mm or 6mm/ Q235 carbon steel
End Plate: 5mm or 6mm /Q235 carbon steel
Diesel Engine: WEICHAI, Tianhe 4100/4102 or other brand
Compressor: BOHAI 10m³ /12 m³ Or other brand
Manhole Cover: Carbon steel or Aluminum Diameter, 500mm
Discharging ValveDiameter is 3 or 4 inch (Material: Aluminum )
Discharging Pipe: 3 or 4 inch rubber hose, 1pcs, 6m/each
Cat WalkWith: (Common model or special design)
Chassis:
Main Beams: Welding Design, Q345 carbon steel
3 axles, 16T, HUAJING brand
Landing Gear: JOST (D200T)or CHINA BRAND 28T
King Pin: JOST 2.00 or 3.5 inch bolt-in king pin
Suspension: "Mechanical suspension/Germany or America type /Air Suspension
Leaf Spring: 90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12
Pneumatic Braking System: WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); 45L air tanks.
Rim: 9.00-22.5/ China Brand
Tire315 80R22.5 Brand can be Optional
ABS: Optional
Painting: Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Accessories: One standard tool box
Shipping Terms: By Bulk Cargo, RORO

WELCOME YOU AND YOUR FRIENDS COME TO VISIT OUR COMPANY AT ANY TIME!
2 or 3 axles bulke cement tanker semi trailer,
We do the trailer according to your specail requirement.

(Most of the trading company copy our pictures, drawings, but never passed us, ,

WELCOME YOU AND YOUR FRIENDS COME TO VISIT OUR COMPANY AT ANY TIME!
