2015 China Manufacturer Cement Bulk Trailer for Sale

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:$14500.0 - $15000.0 / Piece

Min. Order (Pieces)	Unit Price
1.0	US $ 15000/ Piece
10.0	US $ 14500/ Piece

Trade Terms: FOB

Payment Terms: L/C, T/T

Price Valid Time:From Mar 10, 2015 To Jun 03, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:CTY9316GHY

Axle:Fuwa/BPW/Hj Brand

Twist Lock:12 Pieces

Color:Any Color

Condition:New

Emergency Valve:Wabco

King Pin:Jost Brand

Material:Steel

Scale:Heavy Duty

Certification:CCC, ISO, SGS

Export Markets:South America, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia

Additional Info.

Trademark:TONGYADA

Packing:Nake

Standard:SGS

Origin:Shandong, China

HS Code:87164000

Production Capacity:300units Per Month

Product Description

Our machines/bulk cement tanker:
We have first class numerical control cutting machine, automatic welding machine, large-size Bending Machine and Board Press machine in china, tanker body automatic welding tipper, the greatest entire-car-passing type shot blasting machine in Shandong Province, 21m length super spray painting and baking varnish room, Switzerland four-wheel ATD-GPS and 400 sets TEST EQUIPMENT which are advanced technology and Hi-Tech equipments.

Main Dimensions
Tank Body
Shape	Optional ( One Silo with V type or Two ,Three Silos Design)
Dimension	12000mm2490mm3990mm ( Exact size depends on the final design)
Tare weight	About 7500KGS-15000KGS
Total Volume(m3)	25m³-68 m³
Tanker Body Material	5mm or 6mm/ Q235 carbon steel
End Plate	5mm or 6mm /Q235 carbon steel
Diesel Engine	WEICHAI ,Tianhe 4100/4102 or other brand
Compressor	BOHAI 10m³/12 m³or other brand
Manhole Cover	Carbon steel or Aluminum 500mm
Discharging Valve	Diameter is 3 or 4 inch (Material: Aluminum )
Discharging Pipe	3 or 4 inch rubber hose, 1pcs, 6m/each
Cat Walk	With (Common model or special design)
Chassis
Main Beams	Welding Design ,Q345 carbon steel
Axle	2 or 3 axles, 12T/13T/16T, BPW/FUWA/HUAJING brand
Landing Gear	JOST (D200T)or CHINA BRAND 28T
King Pin	JOST 2.00 or 3.5 inch bolt-in king pin
Suspension	Mechanical suspension/Germany or America type /Air Suspension
Leaf Spring	90(W)mm13(Thickness)mm10 Layer or 100mm12mm12
Pneumatic Braking System	WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); 45L air tanks.
Rim	9.00-22.5/8.00-20/8.5-20 China Brand
Tire	12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Brand can be Optional
ABS	Optional
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Accessories	One standard tool box
Shipping Terms	By Bulk Cargo ,RORO

WELCOME YOU AND YOUR FRIENDS COME TO VISIT OUR COMPANY AT ANY TIME!

1. Bulk cement tanker, bulk cement truck) alias cement tanker, powder material. Used to transport bulk cement,coal, ash or other powder. Mainly for the use of cement plant, cement warehouses and large construction sites, can save a lot of packaging and loading and unloading work.

Product Description
We have well experienced in reseaching and developing different
    trailers:container trailer, low bed trailer, side wall semi trailer, stake
    semi trailer, tank trailer and heavy duty trailer etc.
High tensile strength steel Q345B for I-beam,Q235B for tank body
Axle:German or American style from 12 tons to 20 tons
Suspension:Mechanical suspension, air suspension or bogie
     suspension.
Tyre:11.00R20, 11R22.5, 12.00R20 or 12R22.5
     (Other size is optional)
King pin:Optional for 2" or 3.5" Kingpin
Volume:From 35,000 Liters to 60,000 Liters
Landing Gear:"Jost" landing gear
1. Send us inquiries on your desired product / mdel through our contact information.
2. We shall reply you within 12 hours.
3. Negotiations on your needed configuration.
4. Configuration on the tech data.
5. Sign contract.
6.30% down payment or LC issuing.
7. Production
8. Manufacturig process updated news.
9. Production completement.
10. Shipment
11. Custom Clearance
12. A/S service for 1 year.

Functions :
1. This series tank semi trailers are mainly used in heavy duty transportation for construction or logistic companies, such as fuel oil or liquid transporting
2. The volume varies widely from 20cube meters to75cube meters, we can manufacture it according to your needs.
3. The axles can be Fuwa / Bpw with different tonnages by your need with price differences.
4. The suspensions can be: Air suspension, mechanic (leaf spring suspension), bogie suspension, etc
5. The loading deck can be concave beams, tire appeared cover, totally flatbed, or extendable.
6. The loading ramps can be rear end designed, or front loading ladders, which can be mechanic spring ladders and hydraulic loading ramps by different needs
