Model#
|
QYZ3254SMG384
|
Driving type:
|
6*4
|
Engine
|
Emission standard: Euro 3
|
Make: Fiat (By SAIC FIAT HONGYAN)
|
Engine: Cursor 9 380
|
4 stroke direct injection diesel engine
|
6 cylinder in-line with water-cooling, turbo-charging and inter-cooling
|
Maximum output: 380hp
|
Maximum torque: 1300NM at 1200~1600rpm
|
Bore:117mm Stroke:135mm
|
Displacement: 9.7L Compression ratio:17 : 1
|
Specific consumlption:196g/k Wh,
|
Cooling system filling quantity(long-term filling): 40L
|
Clutch
|
Single-plate dry coil-spring clutch, diameter 430mm, mechanically operating with air assistance.
|
Transmission
|
Transmission model:12JSD180T
(By FULLER Technology)
|
Propeller shaft
|
Double universal propeller shaft with gear-shaped coupling flange
|
Front axle
|
Steering with double T-cross section
|
Rear axle
|
Casting steel axle housing, central double reduction gear with planetary wheel reduction and differential locks between wheels and axles
Ratio: 5.73
|
Chassis
|
Frame: U-profile parallel ladder type with section of 865в317в8+8mm, all cold riveted cross members
Front suspension: 9 semi-elliptic leaf springs with bogie spring
Rear suspension: 12 semi-elliptic leaf springs with bogie spring
Spare wheel carrier: with one spare wheel
Fuel tank: with 350L fuel tank with locking fuel cap
|
Steering (LHD)
|
CQ8111, hydraulic steering with power assistance (By Licensed ZF technology)
Ratio: 26.2:1
|
Brakes:
|
Service brake: dual circuit compressed air brake
Parking brake(emergency brake): spring energy, compressed air operating on rear wheels
Auxiliary brake: engine exhaust brake
|
Wheels & Tires
|
Rims: 8.5-20, 10 hole-steel Tires:12:00R20 (with one spare tire)
|
Cab
|
Genlyon cab, Designed based on IVECO Stralis, offers most new features of 2008 stralis cabin. Specially signed cabin external lines to achieve high aerodynamic efficiency: the air suspension floating cabin; European island-surrounding style dashboard with LED display; air shock absorber seat which can be adjusted in 6 different directions (front, rear, left, right as well as tilt), extra room; Siemens stereo radio / CD player, high efficient A/C system with Max 5000W refrigerating output; silent cab interior with noise control level at 68╠2 dB.
|
Electrics
|
Operating voltage: 24V, negative grounded,
Starter: 24V, 5.4 kw
Alternator: 28V, 1500kw; Batteries:2в12,165Ah
Cigar-lighter, horn, headlamp, fog light, reverse lamp
|
Dimensions (mm)
|
Wheel base
|
3775+1400
|
Front wheel track
|
2006
|
Rear wheel track
|
1850
|
Front overhang
|
1435
|
Rear overhang
|
1765
|
Overall dimension
|
8375*2500*3510mm)
|
Cargo box size
|
5600*2300*1500(bottom:12mm, side: 8mm)
|
Hydraulic system
|
Front hydraulic system HYVA FC149mm
|
Weight (kg)
|
Permissible loading capacity on chassis
|
12780 Kg
|
Dead weight
|
12090 Kg
|
Front axle loading capacity
|
6500 Kg
|
Rear axle loading capacity
|
16000в2 Kg
|
Performance
|
Maximum driving speed (km/h)
|
80
|
Maximum grade ability (%)
|
38
|
Fuel consumption (L/100km)
|
30
|
