16m Tri Axle Low Bed Large Scale Cargo Semi Trailer

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Price:

Min. order:1 Piece

Trade Terms:FOB, CFR, CIF, EXW

Payment Terms:L/C, T/T, Paypal, Money Gram, Western Union

Trademark:JUPITER

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:FTW9750TDP

Type:Towing Pin

Towing Pin Material:Carbon Steel

Impeller Type:Closed Type

Hook Type:Single

Universal Joint Type:Flexible Universal Joint

Brake Pad Material:Ceramic

Towing Pin Type:Mushroom Type

Towing Pin Diameter:50mm

Differential Gear Type:Gear Type

Independent Suspension Type:Trailing Arm Type

Size:as Your Request

Colour:as Your Requirement

Item:Cargo Semi Trailer

Export Markets:North America, South America, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia

Additional Info.

Trademark:JUPITER

Packing:Nude, Coating with Wax

Standard:CCC

Origin:China

HS Code:87163910

Production Capacity:90 Pieces/Month

Product Description

Virtue: Low loading floor, the upper part provide large loading space, low center gravity, which makes the vehicle very safe
Mainly suitable for transportation of large mechanical devices, large scale cargo, the highway construction equipments, the large tanks, the extra-high containers, all kinds of steel products
Dimensions:
Overall dimensions (mm): 16, 280 × 3, 000 × 3, 100
Front overhang (mm): 650
King pin setting (mm):
Wheel base (mm): 10, 675 + 1, 310 + 1, 310
Top flange thickness (mm): 16
Middle flange thickness (mm): 10
Bottom flange thickness (mm): 20
Floor thickness (mm): 4
Front fitting radius:
Rear tractor clearance radius:
Weight:
Tare weight (kg): 12, 500
Max payload (kg): 75, 000
Total weigh (kg): 87, 500
Running gear:
Suspension: Fuwa/9-leaf spring
Axles: BPW 14
Wheel rim: 8.25 X 22.5 (13 sets)
Tire: 11R22.5 (13 sets)
Kingpin: JOST 3' 5'' bolt-in
Twist lock: Without
Landing gear:
Leg: Jost C200
Rated capacity:
Ramp: 8 pieces
Air system:
Relay valve: 2 unit of WABCO 4 relay valve
ABS: Without
Air tank: 2 units of reliable local brand 48L
Brake chamber: 4 units of T30/30, 2 units of T30
Electrical system:
Voltage: 24V
Receptacle: 7 way socket
Light: Bulb
Else: Color, tool box, mudguard, side guard, spare tire holder
All of the above could be changed according to customer's requirements
As the requirements of the customers in different countries are different, we can design for our customer's special need
