14 Ton XCMG Mechanical Single Drum Road Roller Xs142j for Sale

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 1000000/ Piece

Price:US $1000000.0 / Piece

Trade Terms: FOB, CFR, CIF, FAS, CIP, CPT, FCA

Payment Terms: L/C, T/T, D/P, Paypal, Money Gram, Western Union

Price Valid Time:From Apr 17, 2015 To Jul 15, 2016

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:XS142J

Type:Road Roller

Working Method:Vibration

Axle:Triaxial Three-Wheel

Color:Yellow

Export Markets:Global

Additional Info.

Trademark:XCMG

Packing:Nude, Suitable for Shiping

Standard:ISO

Origin:Jiangsu, China

Production Capacity:100 Sets/Month

Product Description

XS142J Mechanical drive vibratory roller
1. Drive: Mechanical drive
2. Drum: Single drum
3. Model: XS142J
4. Shipment: 40HQ

XS142J/XS162J/XS182J vibratory compactor is a kind of heavy duty self-propelled vibratory compactor. It can effectively compact various soil layers and rock fill, and can be applied to the constructions of modern freeways, airports, embankment fill, ports, dams, railways, mines, etc.
Performance feature
The spacious and bright cab features wide view and comfort.
Simple operation
The humanity instrument panel has a reasonable layout, all the control buttons are clear at a glance.
Adopt the gearbox with synchronizer, which is easy to operate.
The special compactor drive axle has the function of preventing slipping, featuring strong traction.
Reliable and durable hydraulic system
The standard configuration includes imported open gear pump and motor. The optional configuration includes closed hydraulic vibration system, imported piston pump, motor (16t, 18t). All those have a long service life, supplying stable start-oscillation and oscillation stop and high compacting quality.
Energy-saving and environmental friendly power
Shanghai Diesel Engine 114 series water-cooled engine has low noise, meeting the emission standard of European I. The maintenance-free battery can be started easily and work smoothly in low temperature.
High efficient and reliable vibratory compacting system
Unique drum structure features good rigidity and intensity. The bearing adopts short cylindrical bearing, featuring high rotary speed limit and strong bearing capacity. The left vibration chamber and right vibration chamber are symmetrical, avoiding the polarization of the drum.
The vibratory bearing can be lubricated when the compactor travels, which is simple and convenient, ensuring a quite low lubricating system failure rate.
Adopt the numerical control blanking, numerical control plate rolling, numerical control bender, and numerical control horizontal machining center to ensure the precision of the whole machining.
Optional configuration
The integral convex block drum, split convex block drum, and the cab with air conditioning.
Convenient maintenance
The engine cover is easy to open, and the opening angle is large, which make the maintenance part accessible.
The high positioned air intake prolongs the maintenance interval of the air filter.

Category	Items	Value
working mass	kg	14000
Front Drum Module Mass	kg	4700
Rear Drum Module Mass	kg	7300
static linear load	N/cm	336
I speed	km/h	2.37
II speed	km/h	4.41
III speed	km/h	8.11
Theoretical gradeability	%	30
Min. Outer turning radius	mm	5600
Min.Clearance	mm	385
Max.Shell protuberating	mm	120
Steering angle		34
Oscillating Angle		11
Vibrating frequency	Hz	28
Norminal amplitude(High/low)	mm	2.0/1.0
Centrifugal force@High/low Amp	KN	270.5/137
Vibrating Drum Diameter	mm	1523
Vibrating Drum Width	mm	2130
Engine model		Shanghai 4135
Type		water cooling, Aspiration
Max. Power@1500r/min	kw	73.5
Total length	mm	5545
Total width	mm	2370
Total height	mm	3160
