11.2m Two Axle Low Bed Semi Trailer

More Views

Be the first to review this product

More than 10 available

Availability: In stock

Min. Order (Pieces)	Unit Price
1.0	US $ 20000/ Piece

Price:US $20000.0 / Piece

Trade Terms: FOB, CFR, CIF, EXW

Payment Terms: L/C, T/T, Paypal, Money Gram, Western Union

Price Valid Time:From Jan 07, 2015 To Apr 07, 2015

Disclaimer: Only available in certain countries some restrictions may apply

Inquire Now

Also available at

Login or Signup to View Links.

Description

Details

Basic Info.

Model NO.:FTW9330TD

Type:Towing Pin

Towing Pin Material:Carbon Steel

Impeller Type:Closed Type

Hook Type:Single

Universal Joint Type:Flexible Universal Joint

Brake Pad Material:Ceramic

Towing Pin Type:Mushroom Type

Towing Pin Diameter:50mm

Differential Gear Type:Gear Type

Independent Suspension Type:Trailing Arm Type

Size:as Your Request

Colour:as Your Request

Export Markets:North America, South America, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia

Additional Info.

Trademark:JUPITER

Packing:Nude, Coating with Wax

Standard:CCC

Origin:China

HS Code:87163910

Production Capacity:90 Pieces/Month

Product Description

Virtue: Low-loading floor, the upper part provide large loading space, low-center gravity, which makes the vehicle very safe mainly suitable for transportation of large mechanical devices, large scale cargo, the highway construction equipment, the large tanks, the extra-high-containers, all kinds of steel products
Dimensions:
Overall dimensions: 11, 200× 3, 000× 3, 070mm
Front over-hang: 450mm
King pin setting:
Wheel base: 8, 100+1, 310mm
Loading surface height:
Top flange thickness: 20mm
Middle flange thickness: 10mm
Bottom flange thickness: 20mm
Floor thickness: 4mm
Front fitting radius
Rear tractor clearance radius
Weight:
Tare weight: 8, 000kg
Maximum payload: 25, 000kg
Total weight: 33, 000kg
Running gear
Suspension: Fuwa/7-leaf spring
Axles: FUWA 13
Wheel rim: 8.25 X 22.5 (8 sets)
Tyre: 11R22.5 (8 sets)
Kingpin: BH-KW 2-inch welding type
Twist lock: Without
Landing gear
Leg: FUWA or Jost
Rated capacity:
Ramp: 8 pieces
Air system
Relay valve: 1 unit of East Star 4 relay valve
ABS: Without
Air tank: 1 units of reliable local brand 48L
Brake chamber: 2 units of T30/30, 2 units of T30
Electrical system:
Voltage: 24V
Receptacle: 7-way socket
Light: LED
Else: Color, tool box, mudguard, side guard, spare tyre holder
All of the above could be changed according to customers' requirement
As the requirements of the customers in different countries are different, we can design for our customers' special need
